Audi TT 8J facelift (2010-2014) Anti-theft circuit

ANTI-THEFT IMMOBILIZER CONTROL MODULE ANTI-THEFT IMMOBILIZER READING COIL BLK WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE CENTRAL LOCKING SAFE INDICATOR LAMP COMPUTER DATA LINES SYSTEM DISPLAY UNIT DRIVER DOOR CONTROL MODULE (IN DRIVER'S DOOR) DRIVER'S DOOR CENTRAL LOCKING LOCK UNIT DRIVER'S INTERIOR LOCKING BUTTON ENGINE HOOD CONTACT SWITCH FUSE 12 FUSE 26 FUSE 27 FUSE PANEL SC (LEFT SIDE OF DASH) GRN/GRY WIRE GRN/VIO WIRE GRY/GRN WIRE GRY/VIO WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE INTERIOR MONITORING SWITCH, SWITCH ILLUMINATION BLUB NCA WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE RED/GRN WIRE RED/YEL WIRE TRUNK LID ALARM SWITCH, REAR LID CENTRAL LOCKING SYSTEM MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO/BLU WIRE VIO/GRN WIRE YEL/RED WIRE

ALARM HORN (IF EQUIPPED) ANTENNA AMPLIFIER ANTI THEFT ALARM SYSTEM SENSOR (CENTER FRONT OF ROOF) BLK WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE COUPE FRONT PASSENGER'S DOOR CENTRAL FRONT PASSENGER'S INTERIOR LOCKING BUTTON FUEL FILLER DOOR UNLOCK MOTOR FUSE 10 FUSE 7 FUSE PANEL F GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRY/GRN WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL SB (LEFT SIDE OF ENGINE COMPT) FUSE HOLDER 1 FUSE 5 LOCKING LOCK UNIT NCA WIRE PARKING BRAKE CONTACT SWITCH PILLAR) REAR WINDOW GLASS BREAKAGE SENSOR (COUPE W/ ANTI-THEFT ALARM) RED/GRN WIRE RED/YEL WIRE VIO WIRE VIO/BLU WIRE VIO/GRN WIRE
