Anti-lock brakes circuit for Audi TT 8J facelift (2010-2014)

15 14 19 COMPUTER DATA LINES SYSTEM 2.0L 2.0L 2.5L CDMA CETA ABS CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) ABS HYDRAULIC PUMP ABS HYDRAULIC UNIT ASR/ESP BUTTION BLK WIRE BLK/RED WIRE BLK/YEL WIRE BRAKE BOOSTER VACUUM SENSOR (INTEGRATED INTO BRAKE BOOSTER) BRAKE LIGHT/ BRAKE PEDAL SWITCH BRAKE PRESSURE SENSOR 1 BRN WIRE BRN/GRY WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 1 DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 2 DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 ENGINE CONTROL MODULE (CDMA, CETA: CENTER REAR OF ENGINE COMPT) ESP SENSOR UNIT (ON CENTER CONSOLE, IN FRONT OF SELECTOR LEVER) FRONT/CENTER CONSOLE CONTROL HEAD FUSE GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL FUSE SC (LEFT SIDE OF DASH) HOT AT ALL TIMES FUSE PANEL FUSE SD HOT AT ALL TIMES FUSE PANEL FUSE SF HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LEFT FRONT ABS INLET VALVE LEFT FRONT ABS OUTLET VALVE LEFT FRONT ABS WHEEL SPEED SENSOR (AT LEFT FRONT HUB ASSEMBLY) LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE LEFT REAR ABS WHEEL SPEED SENSOR (AT LEFT REAR HUB ASSEMBLY) NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT FRONT ABS WHEEL SPEED SENSOR (AT RIGHT FRONT HUB ASSEMBLY) RIGHT REAR ABS INLET VALVE RIGHT REAR ABS OUTLET VALVE RIGHT REAR ABS WHEEL SPEED SENSOR (AT RIGHT REAR HUB ASSEMBLY) STEERING ANGLE SENSOR (AT STEERING COLUMN) STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (AT STEERING COLUMN) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO/RED WIRE VIO/YEL WIRE WARNING SYSTEMS WHT WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/BLK WIRE
