Audi TT 8J facelift (2010-2014) external audio source connection Wiring diagrams
This page contains all the electrical diagrams for the component. external audio source connection, in which he is found in the car Audi TT 8J facelift (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
external audio source connection wiring diagram (1 of 4)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTER MID/HIGH RANGE SPEAKER
CENTER SPEAKER
COMPUTER DATA LINES SYSTEM
COUPE
DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT)
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 35
FUSE PANEL SC (LEFT SIDE OF DASH)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
INSIDE MICROPHONE (W/ VOICE CINTROL)
LEFT FRONT BASS SPEAKER
LEFT FRONT MIDRANGE SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR MID/LOW RANGE SPEAKER
LEFT REAR TREBLE SPEAKER
MICROPHONE UNIT
NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA)
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT MIDRANGE SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
ROADSTER
SATELLITE ANTENNA
TELEPHONE MICROPHONE (W/O VOICE CINTROL)
W/O W/ VOICE VOICE CONTROL CONTROL
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit, with bose (2 of 2) -> EXTERNAL AUDIO SOURCE CONNECTION
external audio source connection wiring diagram (2 of 4)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTER MID/HIGH RANGE SPEAKER
COMPUTER DATA LINES SYSTEM
COUPE
DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT)
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 35
FUSE PANEL SC (LEFT SIDE OF DASH)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
INSIDE MICROPHONE (W/ VOICE CONTROL)
LEFT FRONT BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LEFT REAR MID/LOW RANGE SPEAKER
LEFT REAR TREBLE SPEAKER
MICROPHONE UNIT
NAVIGATION SYSTEM W/ CD DRIVE CONTROL MODULE
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA)
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
ROADSTER
SATELLITE ANTENNA
TELEPHONE MICROPHONE (W/O VOICE CONTROL)
W/O W/ VOICE VOICE CONTROL CONTROL
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, without bose (2 of 2) -> EXTERNAL AUDIO SOURCE CONNECTION
external audio source connection wiring diagram (3 of 4)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTER MID/HIGH RANGE SPEAKER
CENTER SPEAKER
COMPUTER DATA LINES SYSTEM
DIGITAL SOUND SYSTEM CONTROL MODULE
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 35
FUSE PANEL SC (LEFT SIDE OF DASH)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT BASS SPEAKER
LEFT FRONT MIDRANGE SPEAKER
LEFT FRONT TREBLE SPEAKER
MICROPHONE UNIT
ORG/BRN WIRE
ORG/VIO WIRE
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT MIDRANGE SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, with bose (2 of 2) -> EXTERNAL AUDIO SOURCE CONNECTION
external audio source connection wiring diagram (4 of 4)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
CENTER MID/HIGH RANGE SPEAKER
COMPUTER DATA LINES SYSTEM
DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 35
FUSE PANEL SC (LEFT SIDE OF DASH)
GRN WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT BASS SPEAKER
LEFT FRONT TREBLE SPEAKER
LUGGAGE COMPT)
ORG/BRN WIRE
ORG/VIO WIRE
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID/LOW RANGE SPEAKER
RIGHT REAR TREBLE SPEAKER
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, without bose (2 of 2) -> EXTERNAL AUDIO SOURCE CONNECTION
