Audi TT 8J facelift (2010-2014) electronic abs damping control control module module Wiring diagram
This page shows the only wiring diagram for the component.electronic abs damping control control module module, which is found in the car Audi TT 8J facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic abs damping control control module module (1 of 1)
1/5
BLK WIRE
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER SOCKET
CONVERTIBLE TOP CONTROL MODULE
CONVERTIBLE VEHICLE ELECTRICAL TOP SYSTEM CONTROL CONTROL MODULE MODULE
DRIVER'S BACKREST STOP SWITCH
DRIVER'S POWER SEAT SWITCH
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
ELECTRONIC ABS DAMPING CONTROL CONTROL MODULE MODULE
FROM FUSE PANEL SC (DIAGRAM 1 OF 6)
FROM FUSE PANEL SC (DIAGRAM 2 OF 6)
FRONT PASSENGER'S BACKREST STOP SWITCH
FRONT PASSENGER'S POWER SEAT SWITCH
FRONT PASSENGER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FUEL PUMP CONTROL MODULE (2.0L)
FUSE 10
FUSE 11 FUSE 12
FUSE 2 FUSE 4
FUSE 30
FUSE 31
FUSE 32 FUSE 38
FUSE 33
FUSE 6 FUSE 5
FUSE 7
FUSE 9 FUSE 8
FUSE PANEL SC FUSE 29
FUSE PANEL SF FUSE 1
GRN WIRE
GRY WIRE
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
POWER SUPPLY RELAY (TERMINAL 50)
POWER SUPPLY RELAY 2 (TERMINAL
RED WIRE
RED/GRN WIRE
RELAY PANEL (BELOW INSTRUMENT PANEL) (BELOW LEFT SIDE OF INSTRUMENT PANEL)
RELAY PANEL (ON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE)
STARTER
TO FUSE PANEL SC (DIAGRAM 1 OF 6)
TO FUSE PANEL SC (DIAGRAM 2 OF 6)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
W/O FOLDING BACKREST W/ FOLDING BACKREST W/O LUMBAR SEAT
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> ELECTRONIC ABS DAMPING CONTROL CONTROL MODULE MODULE
