Audi TT 8J facelift (2010-2014) driver's vanity mirror light contact switch Wiring diagram
This page shows the only wiring diagram for the component.driver's vanity mirror light contact switch, which is found in the car Audi TT 8J facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's vanity mirror light contact switch (1 of 1)
AUTOMATIC DAY/NIGHT INTERIOR MIRROR
BLU/GRY WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE (IN DRIVER'S DOOR)
DRIVER MAP/ READING LIGHT
DRIVER'S DOOR CONTACT SWITCH
DRIVER'S DOOR WARNING LIGHT
DRIVER'S INTERIOR LOCKING BUTTON
DRIVER'S READING LIGHT BUTTON
DRIVER'S VANITY MIRROR LIGHT CONTACT SWITCH
DRIVER`S ILLUMINATED MAKE-UP MIRROR LIGHT
FRONT INTERIOR LAMP BUTTON
FRONT INTERIOR LIGHT
FRONT PASSENGER DOOR CONTROL MODULE (IN PASSENGER'S DOOR)
FRONT PASSENGER'S DOOR CONTACT SWITCH
FRONT PASSENGER'S DOOR WARNING LIGHT
FRONT PASSENGER'S ILLUMINATED MAKE-UP MIRROR LIGHT
FRONT PASSENGER'S INTERIOR LOCKING BUTTON
FRONT PASSENGER'S MAP/READING LIGHT
FRONT PASSENGER'S READING LIGHT BUTTON
FRONT PASSENGER'S VANITY MIRROR LIGHT CONTACT SWITCH
FUSE
FUSE PANEL F
FUSE PANEL SC (LEFT SIDE OF DASH)
GLOVE COMPARTMENT LAMP SWITCH
GLOVE COMPARTMENT LIGHT
GRN/RED WIRE
GRY/BLU WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FRONT ENTRY LIGHT
LEFT FRONT FOOTWELL ILLUMINATION (W/ LED LIGHT PACKAGE)
LUGGAGE COMPARTMENT LIGHT
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT ENTRY LIGHT
RIGHT FRONT FOOTWELL ILLUMINATION (W/ LED LIGHT PACKAGE)
SWITCH ILLUMINATION LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH)
VIO/BLU WIRE
VIO/WHT WIRE
W/ AUXILIARY LAMPS
WHT/GRY WIRE
Go to component -> Courtesy lamps circuit -> DRIVER'S VANITY MIRROR LIGHT CONTACT SWITCH
