Car Wiring Diagrams for Warning systems circuit for Audi TT 8J (2006-2010)

BRN WIRE COMPUTER DATA LINES SYSTEM FRONT/CENTER CONSOLE CONTROL HEAD FUSE FUSE PANEL SC (LEFT SIDE OF DASH) GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE PANEL C FUSE 17 INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT TIRE PRESSURE MONITORING SENSOR LEFT REAR TIRE PRESSURE MONITORING SENSOR ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/GRY WIRE RIGHT FRONT TIRE PRESSURE MONITORING SENSOR RIGHT REAR TIRE PRESSURE MONITORING SENSOR SWITCH ILLUMINATION LAMP TIRE PRESSURE MONITOR DISPLAY IND LAMP TIRE PRESSURE MONITORING BUTTON TIRE PRESSURE MONITORING CONTROL MODULE (NEAR LEFT SIDE OF DASH) YEL/BLU WIRE
