Trunk & fuel door release circuit for Audi TT 8J (2006-2010)
Trunk & fuel door release circuit
BLK/RED WIRE
BLU/BRN WIRE
BRN WIRE
BRN/VIO WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S DOOR)
FUEL TANK LID UNLOCK MOTOR
FUSE 10
FUSE 26
FUSE PANEL SC (LEFT SIDE OF DASH)
FUSE PANEL SF (RIGHT REAR OF LUGGAGE COMPT)
GRN/GRY WIRE
GRN/VIO WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID REMOTE CONTROL LOCK SWITCH/ FUEL TANK LID UNLOCK BUTTON
RED/GRN WIRE
RED/YEL WIRE
TRUNK LID ALARM SWITCH/DECKLID CENTRAL LOCKING SYSTEM MOTOR
VIO/GRN WIRE
YEL/RED WIRE
