Headlights circuit, with bi-xenon headlights for Audi TT 8J (2006-2010)

BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIMMER SWITCH DRL DISABLE SWITCH (IF EQUIPPED) DRL LAMP/ PARKING LAMP FOG LAMP FRONT TURN SIGNAL FRONT SIDE FUSE FUSE PANEL SC GRN/BRN WIRE GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HDLAMP SW ILL HEADLAMP BEAM ADJUSTMENT MOTOR HEADLAMP CONTROL MODULE HEADLAMP POWER OUTPUT STAGE HEADLIGHT DIMMER/ FLASHER SWITCH HID LAMP HOT AT ALL TIMES LED PARKING LAMP/ DRL MODULE LEFT FRONT FOG LAMP LEFT HEADLIGHT ASSEMBLY LIGHT SWITCH LOW BEAM REFLECTOR MOTOR MARKER LAMP LAMP NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RIGHT FRONT FOG LAMP STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE

BLK WIRE BLK/GRN WIRE BLU WIRE BRN WIRE BRN/YEL WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM DRL LAMP/ PARKING LAMP FRONT SIDE FUSE FUSE PANEL SC (LEFT SIDE OF DASH) GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HEADLAMP BEAM ADJUSTMENT MOTOR HEADLAMP CONTROL MODULE HEADLAMP POWER OUTPUT STAGE HEADLAMP RANGE CONTROL MODULE (LEFT SIDE OF DASH) HID LAMP HOT AT ALL TIMES LED PARKING LAMP/ DRL MODULE FRONT TURN LEFT FRONT LEVEL CONTROL SYSTEM SENSOR (W/O ELECTRONIC DAMPING CONTROL) LEFT REAR LEVEL CONTROL SYSTEM SENSOR (W/O ELECTRONIC DAMPING CONTROL) LOW BEAM REFLECTOR MOTOR MARKER SIGNAL LAMP LAMP ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE PARKING BRAKE RIGHT HEADLIGHT ASSEMBLY WHT WIRE YEL WIRE YEL/BLU WIRE
