Ground distribution circuit for Audi TT 8J (2006-2010)
Ground distribution circuit (1 of 2)
BATTERY
BLK WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
ELECTRONIC DAMPING CONTROL MODULE
FRESH AIR BLOWER CONTROL MODULE, ABS CONTROL MODULE
FRONT/CENTER CONSOLE CONTROL HEAD, PARKING BRAKE CONTACT SWITCH
MODULE, VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE
NAVIGATION SYSTEM W/ SD DRIVE CONTROL MODULE SHIELD
POWER STEERING CONTROL MODULE
RADIO SHIELD, EXTERNAL AUDIO SOURCE CONNECTION SHIELD
RIGHT FRONT FOG LAMP, FUEL PUMP (FP) CONTROL MODULE, FUEL LEVEL SENSOR
RIGHT TAIL LAMP, REAR FOG LIGHT, LUGGAGE COMPARTMENT LIGHT, PARKING AID CONTROL
SUPPRESSOR
TELEPHONE TRANSCEIVER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE, DRIVER'S DOOR CONTROL MODULE
Ground distribution circuit (2 of 2)
AIR BAG CONTROL MODULE
BLK WIRE
BRN WIRE
BRN/GRN WIRE
COOLANT FAN CONTROL (FC) MODULE
COOLANT FAN CONTROL (FC) MODULE, BRAKE PEDAL SWITCH, CLUTCH POSITION SENSOR
DIGITAL SOUND SYSTEM CONTROL MODULE, SATELLITE RADIO
DIRECT SHIFT GEAR BOX (DSG) MECHATRONICS
ENGINE CONTROL MODULE (ECM)
HEATED REAR WINDOW
IGNITION COILS 1, 2, 3, 4 (2.0L TURBO) IGNITION COILS 1, 2, 3, 4, 5, 6 (3.2L)
LEFT TAIL LAMP
MASS AIR FLOW (MAF) SENSOR, ENGINE CONTROL MODULE (ECM)
OIL PRESSURE SWITCH, IGNITION COILS 1, 2, 3, 4 (2.0L TURBO)
POWER STEERING CONTROL MODULE
SECONDARY AIR INJECTION (AIR) PUMP MOTOR, COOLANT FAN CONTROL (FC) MODULE
SUPPRESSOR
