Electronic power steering circuit for Audi TT 8J (2006-2010)
Electronic power steering circuit
11 12 COMPUTER DATA LINES SYSTEM
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
HOT AT ALL TIMES FUSE PANEL SA (LEFT SIDE OF ENGINE COMPT) FUSE 2
HOT AT ALL TIMES FUSE PANEL SC FUSE 6 (LEFT SIDE OF DASH)
LATE PRODUCTION EARLY PRODUCTION
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
POWER STEERING CONTROL MODULE
RED WIRE
STEERING ANGLE SENSOR (AT STEERING COLUMN)
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (AT STEERING COLUMN)
STEERING TORQUE SENSOR
