Active bodyworks circuit for Audi TT 8J (2006-2010)
Active bodyworks circuit
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
FRONT/CENTER CONSOLE CONTROL HEAD (W/ REAR SPOILER ADJUSTMENT)
FUSE 12 (RIGHT REAR OF LUGGAGE COMPT)
FUSE PANEL SF
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
REAR SPOILER ASSEMBLY (IF EQUIPPED)
REAR SPOILER MOTOR
REAR SPOILER REAR ADJUSTMENT SPOILER INDICATOR STOP LAMP SWITCH 2
REAR SPOILER STOP SWITCH 1
REAR SPOILER SWITCH
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
YEL WIRE
