Audi TT 8J (2006-2010) module, vehicle positioning system interface control module Wiring diagram
This page shows the only wiring diagram for the component.module, vehicle positioning system interface control module, which is found in the car Audi TT 8J (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram module, vehicle positioning system interface control module (1 of 1)
BATTERY
BLK WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
ELECTRONIC DAMPING CONTROL MODULE
FRESH AIR BLOWER CONTROL MODULE, ABS CONTROL MODULE
FRONT/CENTER CONSOLE CONTROL HEAD, PARKING BRAKE CONTACT SWITCH
MODULE, VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE
NAVIGATION SYSTEM W/ SD DRIVE CONTROL MODULE SHIELD
POWER STEERING CONTROL MODULE
RADIO SHIELD, EXTERNAL AUDIO SOURCE CONNECTION SHIELD
RIGHT FRONT FOG LAMP, FUEL PUMP (FP) CONTROL MODULE, FUEL LEVEL SENSOR
RIGHT TAIL LAMP, REAR FOG LIGHT, LUGGAGE COMPARTMENT LIGHT, PARKING AID CONTROL
SUPPRESSOR
TELEPHONE TRANSCEIVER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE, DRIVER'S DOOR CONTROL MODULE
Go to component -> Ground distribution circuit (1 of 2) -> MODULE, VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE
