Audi TT 8J (2006-2010) map/reading light 2 1 Wiring diagram

9 10 11 COMPUTER DATA LINES SYSTEM BLU/GRY WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/YEL WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE (IN DRIVER'S DOOR) DRIVER'S DOOR CONTACT SWITCH DRIVER'S DOOR WARNING LIGHT DRIVER'S INTERIOR LOCKING BUTTON DRIVER'S MAKE-UP MIRROR LIGHT CONTACT SWITCH DRIVER'S READING LIGHT BUTTON DRIVER`S ILLUMINATED MAKE-UP MIRROR LIGHT FRONT INTERIOR LAMP BUTTON FRONT INTERIOR LIGHT FRONT PASSENGER DOOR CONTROL MODULE (IN PASSENGER'S DOOR) FRONT PASSENGER'S DOOR CONTACT SWITCH FRONT PASSENGER'S DOOR WARNING LIGHT FRONT PASSENGER'S ILLUMINATED MAKE-UP MIRROR LIGHT FRONT PASSENGER'S INTERIOR LOCKING BUTTON FRONT PASSENGER'S MAKE-UP CONTACT SWITCH FRONT PASSENGER'S MAP/READING LIGHT FRONT PASSENGER'S READING LIGHT BUTTON FUSE FUSE PANEL SC (LEFT SIDE OF DASH) GLOVE COMPARTMENT LAMP SWITCH GLOVE COMPARTMENT LIGHT GRN/RED WIRE GRY/BLU WIRE GRY/VIO WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT LEFT FRONT ENTRY LIGHT LEFT FRONT FOOTWELL ILLUMINATION (W/ LED LIGHT PACKAGE) LIGHT SWITCH LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPT) MAP/READING LIGHT 2 1 ORG/BRN WIRE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM RED/BLK WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT ENTRY LIGHT RIGHT FRONT FOOTWELL ILLUMINATION (W/ LED LIGHT PACKAGE) SWITCH ILLUMINATION LAMP VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO/BLU WIRE VIO/WHT WIRE W/ LED LIGHT PACKAGE WHT/GRY WIRE
