Audi TT RS 8S facelift (2019-2024) 2.0l turbo, a/t circuit

A/T HYDRAULIC PRESSURE SENSOR 1 A/T HYDRAULIC PRESSURE SENSOR 2 BLK WIRE BLK/RED WIRE BLU/GRN WIRE BRAKE LAMP/ BRAKE PEDAL SWITCH BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM COOLING OIL VALVE DHHA DLRA DUAL-CLUTCH TRANSMISSION MECHATRONIC ELECTRONICS BOX) ENGINE CONTROLS SYSTEMS ENGINE/MOTOR CONTROL MODULE FUSE 13 FUSE 6 FUSE 7 FUSE PANEL B GEAR POSITION DISTANCE SENSOR 1 GEAR POSITION DISTANCE SENSOR 2 GEAR POSITION DISTANCE SENSOR 3 GEAR POSITION DISTANCE SENSOR 4 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT MAIN PRESSURE VALVE ORG/BRN WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SOLENOID VALVE 5 SUB-TRANSMISSION 1 VALVE 1 SUB-TRANSMISSION 1 VALVE 2 SUB-TRANSMISSION 1 VALVE 3 SUB-TRANSMISSION 1 VALVE 4 SUB-TRANSMISSION 2 VALVE 1 SUB-TRANSMISSION 2 VALVE 2 SUB-TRANSMISSION 2 VALVE 3 SUB-TRANSMISSION 2 VALVE 4 TEMPERATURE SENSOR TRANSMISSION COOLANT VALVE TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SPEED SENSOR 1 TRANSMISSION INPUT SPEED SENSOR 2 TRANSMISSION OUTPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR 2 WHT/BLU WIRE

BLK WIRE BLK/RED WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 6 FUSE PANEL C GRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL MULTI-FUNCTION STEERING WHEEL CONTROL MODULE NCA WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL SELECTOR LEVER SELECTOR LEVER PARK POSITION LOCK SWITCH SELECTOR LEVER SCALE ILLUMINATION BULB SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT SHIFT LOCK SOLENOID STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL CONNECTOR TIPTRONIC DOWNSHIFT BUTTON TIPTRONIC UPSHIFT BUTTON VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT/BLU WIRE
