Car Wiring Diagrams for Electronic suspension circuit for Audi TT RS 8S facelift (2019-2024)

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/GRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC DAMPING CONTROL MODULE FUSE 13 FUSE PANEL C GRN/RED WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT DAMPING ADJUSTMENT VALVE LEFT REAR DAMPING ADJUSTMENT VALVE LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BRN WIRE RED WIRE RIGHT FRONT DAMPING ADJUSTMENT VALVE RIGHT REAR DAMPING ADJUSTMENT VALVE RIGHT REAR LEVEL CONTROL SYSTEM SENSOR VIO/BRN WIRE WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRY WIRE

2.0L TURBO BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/GRN WIRE CENTER SWITCH MODULE COMPUTER DATA LINES SYSTEM DAMPING ADJUSTMENT BUTTON DRIVING PROFILE SELECTION BUTTON FUSE 9 FUSE PANEL C GRN WIRE HOT AT ALL TIMES LEFT FRONT LEVEL CONTROL SYSTEM SENSOR MULTI-FUNCTION STEERING WHEEL CONTROL MODULE ORG/BRN WIRE RED/BLU WIRE RED/GRY WIRE RIGHT FRONT LEVEL CONTROL SYSTEM SENSOR STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRY WIRE
