Audi TT RS 8S facelift (2019-2024) w/o high beam assist Wiring diagram
This page shows the only wiring diagram for the component.w/o high beam assist, which is found in the car Audi TT RS 8S facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o high beam assist (1 of 1)
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR INTERIOR REAR VIEW MIRROR
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DUAL-CLUTCH TRANSMISSION MECHATRONIC
FUSE 27
FUSE PANEL C
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LEFT BACKUP LAMP BULB
LEFT TAIL LAMP
ORG/BRN WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT BACKUP LAMP BULB
RIGHT TAIL LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
W/O HIGH BEAM ASSIST
Go to component -> Backup lamps circuit -> W/O HIGH BEAM ASSIST
