Audi TT RS 8S facelift (2019-2024) sunlight photo sensor, sunlight photo sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.sunlight photo sensor, sunlight photo sensor 2, which is found in the car Audi TT RS 8S facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunlight photo sensor, sunlight photo sensor 2 (1 of 1)
AIR QUALITY SENSOR, HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT
BLU/BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
FRONT A/C DISPLAY CONTROL HEAD 1
FRONT A/C DISPLAY CONTROL HEAD 2
FRONT A/C DISPLAY CONTROL HEAD 3
FRONT A/C DISPLAY CONTROL HEAD 4
FRONT A/C DISPLAY CONTROL HEAD 5
GRN WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/RED WIRE
HUMIDITY SENSOR/ RAIN/LIGHT RECOGNITION SENSOR
INSIDE REAR VIEW MIRROR
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
SUNLIGHT PHOTO SENSOR, SUNLIGHT PHOTO SENSOR 2
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
W/ SEAT HEATING
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 5) -> SUNLIGHT PHOTO SENSOR, SUNLIGHT PHOTO SENSOR 2
