Audi TT RS 8S facelift (2019-2024) right tail lamp Wiring diagrams

AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR INTERIOR REAR VIEW MIRROR BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DUAL-CLUTCH TRANSMISSION MECHATRONIC FUSE 27 FUSE PANEL C GRN WIRE GRN/RED WIRE HOT AT ALL TIMES LEFT BACKUP LAMP BULB LEFT TAIL LAMP ORG/BRN WIRE RED/BLK WIRE RED/BLU WIRE RIGHT BACKUP LAMP BULB RIGHT TAIL LAMP VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/O HIGH BEAM ASSIST

BACKUP LAMPS CIRCUIT BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FUSE 27 FUSE PANEL C GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT BACKUP LAMP BULB LEFT BRAKE LAMP BULB LEFT REAR FOG LAMP BULB LEFT REAR TURN SIGNAL BULB LEFT TAIL LAMP LEFT TAIL LAMP BULB ORG/BRN WIRE RAIN/LIGHT RECOGNITION SENSOR, HUMIDITY SENSOR RED/BLU WIRE RED/BRN WIRE RIGHT BACKUP LAMP BULB RIGHT BRAKE LAMP BULB RIGHT REAR FOG LAMP BULB RIGHT REAR TURN SIGNAL BULB RIGHT TAIL LAMP RIGHT TAIL LAMP BULB VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE W/ DYNAMIC TURN SIGNALS W/O HID W/ MATRIX BEAM W/O HID, MATRIX BEAM WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL/BLU WIRE

AIR BAG CONTROL MODULE ALL- WHEEL DRIVE CONTROL MODULE ANTENNA AMPLIFIER SHIELD BRN WIRE BRN/BLK WIRE CELLULAR TELEPHONE AMPLIFIER CENTER COUPLING POINT IN LUGGAGE COMPARTMENT CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP LATCH CLOSED SWITCH CONVERTIBLE TOP MOTOR CONVERTIBLE TOP MOTOR 2 COUPE COUPLING POINT ON RIGHT REAR BUMPER DRIVER SEAT BELT SWITCH DRIVER SEAT POSITION SENSOR EXHAUST DOOR CONTROL UNIT EXHAUST DOOR CONTROL UNIT 2 FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH FRONT PASSENGER SEAT POSITION SENSOR FUEL DELIVERY UNIT FUEL PUMP CONTROL MODULE FUEL TANK COUPLING POINT HIGH-MOUNTED BRAKE LAMP BULB LANE CHANGE ASSISTANCE CONTROL MODULE LANE CHANGE ASSISTANCE CONTROL MODULE 2 LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LEFT FRONT SEAT COUPLING STATION LEFT LUGGAGE COMPARTMENT LAMP LEFT REAR LID COUPLING POINT LEFT TAIL LAMP NCA WIRE PASSENGER OCCUPANT DETECTION SENSOR PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE REAR LID LOCK CYLINDER UNLOCK BUTTON REAR LID LOCK UNIT REAR SPOILER REAR VIEW CAMERA REAR VIEW CAMERA SYSTEM CONTROL MODULE REAR VIEW CAMERA SYSTEM CONTROL MODULE SHIELD REAR WINDOW REAR WINDOW DEFOGGER RIGHT FRONT SEAT COUPLING STATION RIGHT LUGGAGE COMPARTMENT LAMP RIGHT REAR LID COUPLING POINT RIGHT TAIL LAMP ROADSTER SUPPRESSOR TIRE PRESSURE MONITORING CONTROL MODULE TV TUNER VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE W/ AUXILIARY LAMPS W/ DYNAMIC TURN SIGNAL
