Audi TT RS 8S facelift (2019-2024) left neck heating control module Wiring diagrams

AIR QUALITY SENSOR ANTI-THEFT ALARM SYSTEM SENSOR BATTERY MONITORING CONTROL MODULE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR DRIVER MULTI- CONTOUR SEAT CONTROL MODULE FRESH AIR BLOWER CONTROL MODULE FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE GARAGE DOOR OPENER CONTROL HEAD GENERATOR, VOLTAGE REGULATOR GRN/BRN WIRE GRY WIRE LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT FRONT SEAT COUPLING STATION LEFT NECK HEATING CONTROL MODULE LIGHT SWITCH ORG/BRN WIRE RAIN/LIGHT RECOGNITION SENSOR (IF EQUIPPED) RED/BLK WIRE REFRIGERANT CIRCUIT PRESSURE SENSOR RIGHT FRONT SEAT COUPLING STATION RIGHT NECK HEATING CONTROL MODULE VIO WIRE VIO/GRN WIRE VIO/WHT WIRE VIO/YEL WIRE W/ INTERIOR MONITORING WHT/BLU WIRE

BLK/RED WIRE BRN WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSE 22 FUSE 26 FUSE 34 FUSE 46 FUSE PANEL C GRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED LEFT FRONT SEAT COUPLING STATION LEFT NECK HEATING CONTROL MODULE MAIN FUSE CARRIER NECK HEATING FAN NECK HEATING RELAY ORG/BRN WIRE RED WIRE RED/GRN WIRE RIGHT FRONT SEAT COUPLING STATION RIGHT NECK HEATING CONTROL MODULE SAFETY FUSE 3 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE YEL/RED WIRE
