Audi TT RS 8S facelift (2019-2024) left front level control system sensor Wiring diagrams

2.0L TURBO BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/GRN WIRE CENTER SWITCH MODULE COMPUTER DATA LINES SYSTEM DAMPING ADJUSTMENT BUTTON DRIVING PROFILE SELECTION BUTTON FUSE 9 FUSE PANEL C GRN WIRE HOT AT ALL TIMES LEFT FRONT LEVEL CONTROL SYSTEM SENSOR MULTI-FUNCTION STEERING WHEEL CONTROL MODULE ORG/BRN WIRE RED/BLU WIRE RED/GRY WIRE RIGHT FRONT LEVEL CONTROL SYSTEM SENSOR STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING WHEEL) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRY WIRE

ABS CONTROL MODULE BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON GRN/BLU WIRE GRN/GRY WIRE GRY WIRE GRY/RED WIRE HEADLAMP RANGE CONTROL MODULE LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BRN WIRE PARKING BRAKE BUTTON POWER DISTRIBUTION SYSTEM RED/BLU WIRE RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP FAN RIGHT HEADLAMP POWER OUTPUT MODULE RIGHT HEADLAMP TEMPERATURE SENSOR 1, RIGHT LOW BEAM HEADLAMP BULB RIGHT HEADLAMP TEMPERATURE SENSOR 2, RIGHT STATIONARY CORNERING LAMP RIGHT HEADLAMP TEMPERATURE SENSOR 3 RIGHT HIGH BEAM HEADLAMP BULB RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LED HEADLAMP POWER OUTPUT MODULE 2 RIGHT MATRIX HEADLAMP POWER OUTPUT MODULE VIO/GRY WIRE WHT WIRE WHT/GRY WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
