Audi TT RS 8S facelift (2019-2024) heater oxygen sensor 1 after catalytic converter Wiring diagram

ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/VIO WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/VIO WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/YEL WIRE COOLING FANS SYSTEM CRUISE CONTROL SYSTEM ELECTRONICS BOX) ENGINE/MOTOR CONTROL MODULE FUSE 10 FUSE 3 FUSE 4 FUSE 5 FUSE 7 FUSE 8 FUSE 9 FUSE PANEL B GRN WIRE GRN/GRY WIRE GRY WIRE GRY/GRN WIRE HEATED OXYGEN SENSOR HEATER OXYGEN SENSOR 1 AFTER CATALYTIC CONVERTER HOT AT ALL TIMES MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY OXYGEN SENSOR 1 (BEFORE CATALYTIC CONVERTER) OXYGEN SENSOR 1 AFTER CATALYTIC CONVERTER OXYGEN SENSOR AFTER CATALYTIC CONVERTER OXYGEN SENSOR HEATER RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SAFETY FUSE TRANSMISSIONS SYSTEM VIO WIRE VIO/RED WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
