Audi TT RS 8S facelift (2019-2024) front passenger backrest stop switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger backrest stop switch, which is found in the car Audi TT RS 8S facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger backrest stop switch (1 of 1)
ANGLE
BACKREST
BLK/RED WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COUPE
FRONT PASSENGER BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER BACKREST STOP SWITCH
FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD
FRONT PASSENGER SEAT ANGLE ADJUSTMENT MOTOR
FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR
FWD/BWD
HEIGHT
HOT AT ALL TIMES
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT SEAT COUPLING STATION
W/O MULTI-CONTOUR SEATS W/ MULTI-CONTOUR SEATS
WHT/BLK WIRE
Go to component -> Power seats circuit (3 of 3) -> FRONT PASSENGER BACKREST STOP SWITCH
