Audi TT RS 8S facelift (2019-2024) fresh air/recirculating air/back pressure door motor, position sensor Wiring diagram
This page shows the only wiring diagram for the component.fresh air/recirculating air/back pressure door motor, position sensor, which is found in the car Audi TT RS 8S facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fresh air/recirculating air/back pressure door motor, position sensor (1 of 1)
A/C COMPRESSOR REGULATOR VALVE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
DEFROSTER DOOR MOTOR, POSITION SENSOR
FRESH AIR/RECIRCULATING AIR/BACK PRESSURE DOOR MOTOR, POSITION SENSOR
FRONT AIR DISTRIBUTION DOOR MOTOR, POSITION SENSOR
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/RED WIRE
GRY/WHT WIRE
LEFT COUPLING POINT IN ENGINE COMPARTMENT
LEFT VENT TEMPERATURE SENSOR
RED/WHT WIRE
RED/YEL WIRE
RIGHT END OF DASH)
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (3 of 5) -> FRESH AIR/RECIRCULATING AIR/BACK PRESSURE DOOR MOTOR, POSITION SENSOR
