Audi TT RS 8S facelift (2019-2024) emergency flasher indicator lamp Wiring diagrams

BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE CENTER INSTRUMENT PANEL SWITCH MODULE EMERGENCY FLASHER BUTTON EMERGENCY FLASHER INDICATOR LAMP FUSE 8 FUSE PANEL C GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE HOT AT ALL TIMES LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP (W/O HID W/ MATRIX BEAM) LEFT FRONT TURN SIGNAL BULB LEFT HEADLAMP TEMPERATURE SENSOR 2, LEFT STATIONARY CORNERING LAMP LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LED HEADLAMP POWER OUTPUT MODULE 2 LICENSE PLATE LAMP LIGHT SWITCH REAR LID LOCK CYLINDER UNLOCK BUTTON RED/BLK WIRE RED/YEL WIRE ROADSTER COUPE VIO/GRN WIRE VIO/RED WIRE WHT WIRE WHT/BLK WIRE WHT/YEL WIRE

2.0L TURBO ACCESS/START AUTHORIZATION BUTTON ACCESS/START AUTHORIZATION CONTROL MODULE ASR/ESP INDICATOR LAMP BLU WIRE BRN WIRE CENTER INSTRUMENT PANEL SWITCH MODULE COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP OPERATION SWITCH CONVERTIBLE WIND DEFLECTOR SWITCH EMERGENCY FLASHER INDICATOR LAMP FRONT ROOF MODULE GRN WIRE GRN/YEL WIRE GRY/BLU WIRE MULTIMEDIA SYSTEM CONTROL HEAD CONTOUR ILLUMINATION LAMP 1 ORG/BRN WIRE PARALLEL PARKING ASSISTANCE CONTROL MODULE PARALLEL PARKING ASSISTANCE INDICATOR LAMP PARKING AID CONTROL MODULE PARKING AID INDICATOR LAMP PARKING BRAKE BUTTON REAR SPOILER ADJUSTMENT INDICATOR LAMP SELECTOR LEVER START/STOP MODE INDICATOR LAMP SWITCH ILLUMINATION BULB VIO/GRN WIRE W/ PARALLEL PARKING ASSISTANCE YEL/BLK WIRE YEL/GRN WIRE
