Audi TT RS 8S facelift (2019-2024) driver seat switch module Wiring diagrams
This page contains all the electrical diagrams for the component. driver seat switch module, in which he is found in the car Audi TT RS 8S facelift (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver seat switch module (1 of 2)
ABS CONTROL MODULE
AIR BAG CONTROL MODULE
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/WHT WIRE
DRIVER BACKREST HEATING ELEMENT
DRIVER MULTI- CONTOUR SEAT CONTROL MODULE
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT BELT SWITCH
DRIVER SEAT HEATING ELEMENT
DRIVER SEAT LEFT BOLSTER HEATING ELEMENT
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER SEAT SWITCH MODULE
DRIVER THORAX AIR BAG IGNITER
FRONT PASSENGER SEAT BELT SWITCH
FRONT PASSENGER SEAT POSITION SENSOR
HEATED DRIVER SEAT EXTENSION
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT SEAT COUPLING STATION
LEFT NECK HEATING FAN
MULTIMEDIA SYSTEM CONTROL HEAD
PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE
PASSENGER SEAT OCCUPANT DETECTION SENSOR
RADIATOR FAN CONTROL MODULE
RIGHT FRONT SEAT COUPLING STATION
W/ ADJUSTABLE SEAT
W/O ADJUSTABLE SEAT
Go to component -> Ground distribution circuit (4 of 6) -> DRIVER SEAT SWITCH MODULE
Wiring diagram driver seat switch module (2 of 2)
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
COUPLING STATION IN LEFT FRONT SEAT
COUPLING STATION IN RIGHT FRONT SEAT
DRIVER MULTI- CONTOUR SEAT CONTROL MODULE
DRIVER MULTI-CONTOUR SEAT COMPRESSOR
DRIVER SEAT SWITCH MODULE
FRONT PASSENGER MULTI-CONTOUR SEAT COMPRESSOR
FRONT PASSENGER MULTI-CONTOUR SEAT CONTROL MODULE
FRONT PASSENGER SEAT SWITCH MODULE
FUSE 20
FUSE PANEL C
GRN WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT COUPLING STATION
RED/GRN WIRE
RIGHT FRONT SEAT COUPLING STATION
VIO/WHT WIRE
YEL/BLU WIRE
Go to component -> Multi contour seat circuit -> DRIVER SEAT SWITCH MODULE
