Audi TT RS 8S facelift (2019-2024) driver lock cylinder contact switch Wiring diagrams
This page contains all the electrical diagrams for the component. driver lock cylinder contact switch, in which he is found in the car Audi TT RS 8S facelift (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver lock cylinder contact switch (1 of 2)
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
CENTRAL LOCKING SAFE INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
DRIVER CENTRAL LOCKING LOCK UNIT
DRIVER DOOR CENTRAL LOCKING SYSTEM MOTOR
DRIVER DOOR CONTACT SWITCH
DRIVER DOOR CONTROL MODULE
DRIVER INTERIOR LOCKING BUTTON
DRIVER LOCK CYLINDER CONTACT SWITCH
FUSE 25
FUSE 39
FUSE 42
FUSE 6
FUSE PANEL C
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT CENTRAL LOCKING SYSTEM ACTUATOR
LEFT FRONT DOOR COUPLING POINT
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
VIO/GRN WIRE
VIO/RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (1 of 3) -> DRIVER LOCK CYLINDER CONTACT SWITCH
Wiring diagram driver lock cylinder contact switch (2 of 2)
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/YEL WIRE
CENTRAL LOCKING SAFE INDICATOR LAMP
COMPUTER DATA LINES SYSTEM
DRIVER CENTRAL LOCKING LOCK UNIT
DRIVER DOOR CENTRAL LOCKING SYSTEM MOTOR
DRIVER DOOR CONTACT SWITCH
DRIVER DOOR CONTROL MODULE
DRIVER INTERIOR LOCKING BUTTON
DRIVER LOCK CYLINDER CONTACT SWITCH
FUSE 25
FUSE 39
FUSE 42
FUSE 6
FUSE PANEL C
GRN/RED WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT CENTRAL LOCKING SYSTEM ACTUATOR
LEFT FRONT DOOR COUPLING POINT
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT DOOR COUPLING POINT
VIO/GRN WIRE
VIO/RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (1 of 3) -> DRIVER LOCK CYLINDER CONTACT SWITCH
