Audi TT RS 8S facelift (2019-2024) driver backrest adjustment motor Wiring diagram
This page shows the only wiring diagram for the component.driver backrest adjustment motor, which is found in the car Audi TT RS 8S facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver backrest adjustment motor (1 of 1)
ANGLE
BACKREST
BLK/RED WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COUPE
DRIVER BACKREST ADJUSTMENT MOTOR
DRIVER BACKREST STOP SWITCH
DRIVER SEAT ADJUSTMENT CONTROL HEAD
DRIVER SEAT ANGLE ADJUSTMENT MOTOR
DRIVER SEAT FORWARD/ BACK ADJUSTMENT MOTOR
DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
FUSE 45
FUSE PANEL C
FWD/BWD
HEIGHT
HOT AT ALL TIMES
LEFT FRONT SEAT COUPLING STATION
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
WHT/BLK WIRE
Go to component -> Power seats circuit (1 of 3) -> DRIVER BACKREST ADJUSTMENT MOTOR
