Audi TT RS 8S facelift (2019-2024) data bus on board diagnostic interface Wiring diagrams
This page contains all the electrical diagrams for the component. data bus on board diagnostic interface, in which he is found in the car Audi TT RS 8S facelift (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram data bus on board diagnostic interface (1 of 3)
BATTERY
BATTERY INTERRUPT IGNITER
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
ELECTRONICS BOX)
FUSE 17
FUSE 2
FUSE PANEL A
FUSE PANEL B
GENERATOR, VOLTAGE REGULATOR
GRN WIRE
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT COUPLING POINT IN ENGINE COMPARTMENT
MAIN FUSE CARRIER
NCA WIRE
ORG/BRN WIRE
RED WIRE
STARTER
SUPPLEMENTAL RESTRAINTS SYSTEM
SUPPRESSOR
VIO/WHT WIRE
WIRE JUNCTION
Go to component -> Charging circuit -> DATA BUS ON BOARD DIAGNOSTIC INTERFACE
Wiring diagram data bus on board diagnostic interface (2 of 3)
12 V SOCKET 2
ANTENNA AMPLIFIER 4 SHIELD
ANTI-THEFT ALARM SYSTEM SENSOR
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BRN WIRE
CIGARETTE LIGHTER
CONVERTIBLE TOP FRONT LOCK SWITCH, LOCKING READINESS SWITCH
COUPE
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DIAGNOSTIC CONNECTION
DIGITAL SOUND SYSTEM CONTROL MODULE
DRIVER ASSISTANCE SYSTEMS FRONT CAMERA
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR DOOR HANDLE SWITCH
DRIVER EXTERIOR DOOR HANDLE TOUCH SENSOR
DRIVER VANITY MIRROR LAMP
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
FRONT ROOF MODULE
GARAGE DOOR OPENER CONTROL HEAD
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER OPERATION BUTTON
INTERIOR REAR VIEW MIRROR
LEFT COUPLING POINT ON REAR LID
LEFT FRONT DOOR COUPLING POINT
LIGHT SWITCH
NECK HEATING RELAY
RAIN/LIGHT RECOGNITION SENSOR
REAR VIEW CAMERA SYSTEM CONTROL MODULE SHIELD
RIGHT FRONT SEAT COUPLING STATION
RIGHT NECK HEATING CONTROL MODULE
RIGHT NECK HEATING FAN
ROADSTER
SATELLITE TUNER ANTENNA SHIELD
SOCKETS RELAY
STEERING COLUMN ELECTRONICS CONTROL MODULE
TERMINAL 15 POWER SUPPLY RELAY
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
Go to component -> Ground distribution circuit (5 of 6) -> DATA BUS ON BOARD DIAGNOSTIC INTERFACE
Wiring diagram data bus on board diagnostic interface (3 of 3)
AIR BAG CONTROL MODULE
ANTI-THEFT ALARM SYSTEM SENSOR
BATTERY
BATTERY INTERRUPT IGNITER
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE
COUPE
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
DIAGNOSTIC CONNECTION
FRONT PASSENGER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD
FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FRONT ROOF MODULE
FUSE 1
FUSE 10
FUSE 2
FUSE 4
FUSE 5
FUSE 53
FUSE 6
FUSE 7
FUSE 8
FUSE 9
GENERATOR, VOLTAGE REGULATOR
GRN WIRE
GRY WIRE
INFORMATION ELECTRONICS CONTROL MODULE 1
INTERIOR REAR VIEW MIRROR
LIGHT SWITCH
MULTIMEDIA SYSTEM CONTROL HEAD
NCA WIRE
NECK HEATING RELAY
PARKING BRAKE BUTTON
POWER STEERING CONTROL MODULE
RADIATOR FAN CONTROL MODULE
RAIN/LIGHT RECOGNITION SENSOR, HUMIDITY SENSOR
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/YEL WIRE
RIGHT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT
RIGHT FRONT SEAT COUPLING STATION
ROADSTER
SAFETY FUSE 1
SAFETY FUSE 2
SAFETY FUSE 3
SAFETY FUSE 4
SELECTOR LEVER
STARTER
STARTING/ CHARGING SYSTEM
STEERING COLUMN ELECTRONICS CONTROL MODULE
TIRE PRESSURE MONITORING CONTROL MODULE
TO FUSE 11 (DIAGRAM 2 OF 5)
TO FUSE 21 (DIAGRAM 2 OF 5)
TO FUSE PANEL B (DIAGRAM 2 OF 5)
TO FUSE PANEL C (DIAGRAM 4 OF 5)
TO FUSE PANEL F (DIAGRAM 5 OF 5)
VIO WIRE
W/ BANG, OLUFSEN SOUND
W/ LUMBAR, POWER SEAT
WHT WIRE
WIRE JUNCTION
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> DATA BUS ON BOARD DIAGNOSTIC INTERFACE
