Audi TT RS 8S facelift (2019-2024) convertible top latch open & close switch Wiring diagram
This page shows the only wiring diagram for the component.convertible top latch open & close switch, which is found in the car Audi TT RS 8S facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top latch open & close switch (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CONVERTIBLE TOP LATCH OPEN & CLOSE SWITCH
CONVERTIBLE TOP LOCKING MOTOR
CONVERTIBLE TOP MOTOR
CONVERTIBLE TOP MOTOR 2
CONVERTIBLE TOP OPERATION SWITCH
CONVERTIBLE WIND DEFLECTOR SWITCH
GRN WIRE
GRY/BLU WIRE
VIO WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> CONVERTIBLE TOP LATCH OPEN & CLOSE SWITCH
