Wiring diagram brn (131 of 132)
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLU/YEL WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRAKE LAMP/ BRAKE PEDAL SWITCH
BRN WIRE
CLUTCH OIL POSITION SENSOR 1
CLUTCH OIL TEMPERATURE SENSOR
CLUTCH PEDAL POSITION SENSOR 2
COMPUTER DATA LINES SYSTEM
COOLING OIL VALVE
DUAL-CLUTCH TRANSMISSION MECHATRONIC (IN TRANSMISSION)
ELECTRONICS BOX)
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 6
FUSE 9
FUSE PANEL B
FUSE PANEL C
GEAR POSITION DISTANCE SENSOR 1
GEAR POSITION DISTANCE SENSOR 2
GEAR POSITION DISTANCE SENSOR 3
GEAR POSITION DISTANCE SENSOR 4
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 30 POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
MAIN PRESSURE VALVE
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
SELECTOR LEVER
SELECTOR LEVER PARK POSITION LOCK SWITCH
SELECTOR LEVER SCALE ILLUMINATION BULB
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
SHIFT LOCK SOLENOID
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL CONNECTOR
SUB-TRANSMISSION 1 VALVE 1
SUB-TRANSMISSION 1 VALVE 2
SUB-TRANSMISSION 1 VALVE 3
SUB-TRANSMISSION 1 VALVE 4
SUB-TRANSMISSION 2 VALVE 1
SUB-TRANSMISSION 2 VALVE 2
SUB-TRANSMISSION 2 VALVE 3
SUB-TRANSMISSION 2 VALVE 4
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSMISSION FLUID TEMPERATURE SENSOR
TRANSMISSION INPUT SPEED SENSOR 1
TRANSMISSION INPUT SPEED SENSOR 2
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/GRN WIRE
WHT/BLU WIRE
Go to component -> 2.5l turbo, a/t circuit -> BRN WIRE
Wiring diagram brn (132 of 132)
ALL- WHEEL DRIVE CONTROL MODULE
ALL-WHEEL DRIVE CLUTCH PUMP
BLK/VIO WIRE
BRN WIRE
CENTER COUPLING POINT IN LUGGAGE COMPARTMENT
COMPUTER DATA LINES SYSTEM
FUSE 44
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT/BLU WIRE
Go to component -> 2.5l turbo, awd circuit -> BRN WIRE
