Audi TT RS 8S facelift (2019-2024) all-wheel drive clutch pump Wiring diagrams
This page contains all the electrical diagrams for the component. all-wheel drive clutch pump, in which he is found in the car Audi TT RS 8S facelift (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram all-wheel drive clutch pump (1 of 2)
ALL- WHEEL DRIVE CONTROL MODULE
ALL-WHEEL DRIVE CLUTCH PUMP
BLK/VIO WIRE
BRN WIRE
CENTER COUPLING POINT IN LUGGAGE COMPARTMENT
COMPUTER DATA LINES SYSTEM
FUSE 44
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT/BLU WIRE
Go to component -> 2.0l turbo, awd circuit -> ALL-WHEEL DRIVE CLUTCH PUMP
Wiring diagram all-wheel drive clutch pump (2 of 2)
ALL- WHEEL DRIVE CONTROL MODULE
ALL-WHEEL DRIVE CLUTCH PUMP
BLK/VIO WIRE
BRN WIRE
CENTER COUPLING POINT IN LUGGAGE COMPARTMENT
COMPUTER DATA LINES SYSTEM
FUSE 44
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED/VIO WIRE
RED/WHT WIRE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT/BLU WIRE
Go to component -> 2.5l turbo, awd circuit -> ALL-WHEEL DRIVE CLUTCH PUMP
