Audi SQ8 I (2019-2023) Supplemental restraints circuit

AIR BAG CONTROL MODULE ANTI-LOCK BRAKES SYSTEM BATTERY INTERRUPT IGNITER BATTERY MONITORING CONTROL MODULE BLK WIRE BLK/BRN WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT SWITCH DRIVER SEAT COUPLING POINT DRIVER SEAT POSITION SENSOR FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER SEAT POSITION SENSOR GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE GRY/YEL WIRE HIGH-VOLTAGE BATTERY REGULATION COUPLING POINT 1 HOT AT ALL TIMES HYBRID BATTERY UNIT ORG/BRN WIRE ORG/GRN WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE POWER DISTRIBUTION SYSTEM RED WIRE RED/VIO WIRE RED/WHT WIRE SEATS SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE WHT WIRE YEL WIRE YEL/GRY WIRE YEL/VIO WIRE

BLK WIRE BLK) RED/BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE BRN/WHT WIRE CENTER SECOND ROW SEAT BELT SWITCH COMPUTER DATA LINES SYSTEM DRIVER HEAD CURTAIN AIR BAG IGNITER DRIVER SIDE REAR SEAT OCCUPANT DETECTION SENSOR DRIVER SIDE SECOND ROW SEAT BELT SWITCH FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER FRONT PASSENGER SEAT HEATING ELEMENT/PASSENGER SEAT OCCUPANT DETECTION SENSOR FUSE 10 FUSE PANEL E GRN WIRE GRY/BLK WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR SEAT COUPLING STATION PASSENGER SIDE REAR SEAT OCCUPANT DETECTION SENSOR PASSENGER SIDE SECOND ROW SEAT BELT SWITCH REAR CENTER SEAT OCCUPANT DETECTION SENSOR RED WIRE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE RIGHT REAR SEAT COUPLING STATION VIO) RED/VIO WIRE VIO/RED WIRE W/ PASSENGER OCCUPANT DETECTION SYSTEM W/O PASSENGER OCCUPANT DETECTION SYSTEM WHT WIRE YEL WIRE

AIR BAG CONTROL MODULE BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER SIDE REAR SEAT BELT TENSIONER IGNITER DRIVER SIDE REAR THORAX AIR BAG IGNITER FUSE 12 FUSE PANEL H GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT "C" PILLAR) LEFT REAR SEAT BELT TENSIONER CONTROL MODULE PASSENGER SIDE REAR SEAT BELT TENSIONER IGNITER PASSENGER SIDE REAR THORAX AIR BAG IGNITER RED WIRE RED/BLK WIRE RED/GRN WIRE RIGHT REAR SEAT BELT TENSIONER CONTROL MODULE VIO WIRE VIO/BRN WIRE W/ REVERSIBLE SEAT BELT TENSIONERS W/O REVERSIBLE SEAT BELT TENSIONERS WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER BELT FORCE LIMITER DRIVER SEAT BELT TENSIONER IGNITER 1 DRIVER SEAT COUPLING POINT DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER BELT FORCE LIMITER FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1 FRONT PASSENGER SEAT COUPLING POINT FRONT PASSENGER THORAX AIR BAG IGNITER FUSE 10 FUSE 15 FUSE 16 FUSE PANEL G FUSE PANEL J GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT SEAT BELT LEFT FRONT SEAT BELT TENSIONER CONTROL MODULE RED WIRE RED/BLK WIRE RED/GRN WIRE RIGHT FRONT SEAT BELT RIGHT FRONT SEAT BELT TENSIONER CONTROL MODULE VIO WIRE VIO/BRN WIRE WHT WIRE YEL WIRE

AIR BAG CONTROL MODULE BLK WIRE BLU WIRE BLU/GRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER AIR BAG IGNITER DRIVER AIR BAG RELEASE VALVE IGNITER DRIVER SEAT BELT TENSIONER IGNITER 2 FRONT PASSENGER SEAT BELT TENSIONER IGNITER 2 GRN WIRE GRY WIRE IGNITER 1 IGNITER 2 PNK WIRE RELEASE VALVE IGNITER FRONT PASSENGER AIR BAG UNIT SPIRAL SPRING STEERING COLUMN ELECTRONICS CONTROL MODULE VIO/BRN WIRE WHT WIRE WHT/RED WIRE YEL WIRE

AIR BAG CONTROL MODULE BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE COUPLING POINT ON LEFT FRONT BUMPER COUPLING POINT ON RIGHT FRONT BUMPER DRIVER FRONT AIR BAG CRASH SENSOR DRIVER SIDE REAR THORAX AIR BAG CRASH SENSOR DRIVER THORAX AIR BAG CRASH SENSOR FRONT PASSENGER THORAX AIR BAG CRASH SENSOR GRN WIRE GRY WIRE LEFT FRONT DOOR COUPLING POINT PASSENGER SIDE FRONT AIR BAG CRASH SENSOR PASSENGER SIDE REAR THORAX AIR BAG CRASH SENSOR RED WIRE RIGHT FRONT DOOR COUPLING POINT THORAX AIR BAG CRASH SENSOR (DRIVER SIDE B-PILLAR) THORAX AIR BAG CRASH SENSOR (FRONT PASSENGER SIDE B-PILLAR) VIO WIRE WHT WIRE WHT/RED WIRE YEL WIRE
