Anti-lock brakes circuit for Audi SQ8 I (2019-2023)

ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) ABS CONTROL MODULE FUSE 1 ABS CONTROL MODULE FUSE 2 ABS HYDRAULIC PUMP BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 1 DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 2 DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 FUSE 11 FUSE 6 FUSE PANEL E GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT COUPLING POINT ON ROOF LEFT FRONT ABS INLET VALVE LEFT FRONT ABS OUTLET VALVE LEFT FRONT ABS WHEEL SPEED SENSOR LEFT PARKING BRAKE MOTOR LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE LEFT REAR ABS WHEEL SPEED SENSOR PNK WIRE REAR OF ENGINE COMPT) RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT PARKING BRAKE MOTOR RIGHT REAR ABS INLET VALVE RIGHT REAR ABS OUTLET VALVE RIGHT REAR ABS WHEEL SPEED SENSOR ROOF RACK RECOGNITION SENSOR VACUUM SENSOR (IF EQUIPPED) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BLU/VIO WIRE BRAKE LAMP SWITCH BRAKE PEDAL POSITION SENSOR BRAKE PEDAL SWITCH BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM ENGINE/MOTOR CONTROL MODULE FUSE 5 FUSE 6 FUSE PANEL A FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER SYSTEM LEFT FRONT BRAKE PAD WEAR SENSOR LEFT REAR BRAKE PAD WEAR SENSOR ORG/BRN WIRE ORG/WHT WIRE RED WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT BRAKE PAD WEAR SENSOR RIGHT REAR BRAKE PAD WEAR SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (LEFT SIDE OF DASH) VIO/RED WIRE WHT/GRN WIRE YEL WIRE

ASR/ESP BUTTON AUTO HOLD BUTTON AUTO HOLD INDICATOR LAMP BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLU/VIO WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE CENTER CONSOLE SWITCH MODULE 1 CENTER COUPLING POINT ON INSTRUMENT PANEL CENTER INSTRUMENT PANEL SWITCH MODULE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON ELECTRO-MECHANICAL PARKING BRAKE INDICATOR LAMP FUSE 11 FUSE 12 FUSE 9 FUSE PANEL F GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE ORG/GRY WIRE PARKING BRAKE BUTTON PARKING BRAKE INDICATOR PNK WIRE PUSH BUTTON ILLUMINATION BULB RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR FOOTWELL STEERING ANGLE SENSOR STEERING COLUMN ELECTRONICS CONTROL MODULE WHT/GRN WIRE

BLK WIRE BLK/RED WIRE BRAKE BOOSTER BRAKE BOOSTER CONTROL MODULE BRAKE FLUID LEVEL WARNING SWITCH BRAKE PEDAL POSITION SENSOR BRAKE PEDAL POSITION SENSOR 2 BRAKE PRESSURE RESERVOIR CONTROL MODULE BRAKE SYSTEM PRESSURE RESERVOIR BRN WIRE BRN/BLK WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 16 FUSE 5 FUSE 7 FUSE PANEL E FUSE PANEL K GRN WIRE GRN/BLK WIRE GRY/BLK WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/GRY WIRE PNK WIRE RECUPERATION BRAKE PRESSURE RESERVOIR MOTOR RED/GRN WIRE RED/YEL WIRE WHT/GRN WIRE WIRE JUNCTION YEL/BLK WIRE
