Audi SQ8 I (2019-2023) selector lever release button, parking lock button Wiring diagram
This page shows the only wiring diagram for the component.selector lever release button, parking lock button, which is found in the car Audi SQ8 I (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram selector lever release button, parking lock button (1 of 1)
4-PIN CONNECTOR
??? ???
BRN WIRE
CENTER CONSOLE
COMPUTER DATA LINES SYSTEM
D/S
FUSE 16
FUSE PANEL F
GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LEFT MULTI-FUNCTION BUTTONS STEERING WHEEL
NCA WIRE
ORG/BRN WIRE
ORG/GRY WIRE
PARKING LOCK IND LAMP
PNK WIRE
RED WIRE
RIGHT MULTI-FUNCTION BUTTONS ON STEERING WHEEL
RIGHT REAR FOOTWELL
SELECTOR LEVER
SELECTOR LEVER POSITION SENSOR
SELECTOR LEVER RELEASE BUTTON, PARKING LOCK BUTTON
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER TRANSMISSION RANGE DISPLAY
SHIFT LOCK SOLENOID
SPIRAL SPRING
STEERING COLUMN ELECTRONICS CONTROL MODULE
TIPTRONIC DOWNSHIFT BUTTON
TIPTRONIC UPSHIFT BUTTON
TRANSVERSE SELECTOR LEVER LOCK MOTOR
TRANSVERSE SELECTOR LEVER LOCK SENSOR
VIO WIRE
Go to component: -> A/t circuit (2 of 2) -> SELECTOR LEVER RELEASE BUTTON, PARKING LOCK BUTTON
