Audi SQ8 I (2019-2023) passenger side rear exit warning lamp Wiring diagram

This page shows the only wiring diagram for the component.passenger side rear exit warning lamp, which is found in the car Audi SQ8 I (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram passenger side rear exit warning lamp (1 of 1)

Wiring diagram passenger side rear exit warning lamp for Audi SQ8 I (2019-2023)

Get access

BLK/YEL WIRE BLU WIRE BRN WIRE BRN/YEL WIRE CONTACT SWITCH FUSE 11 FUSE 7 FUSE PANEL C GRN/BRN WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT REAR DOOR COUPLING POINT PASSENGER SIDE REAR DOOR CONTROL HEAD PASSENGER SIDE REAR DOOR CONTROL MODULE PASSENGER SIDE REAR DOOR LOCK UNIT PASSENGER SIDE REAR ENTRY LAMP PASSENGER SIDE REAR EXIT WARNING LAMP PASSENGER SIDE REAR EXTERIOR DOOR HANDLE ILLUMINATION LAMP PASSENGER SIDE REAR INTERIOR DOOR HANDLE ILLUMINATION BULB PASSENGER SIDE REAR INTERIOR LOCKING BUTTON PASSENGER SIDE REAR SIDE SILL PANEL STRIP AMBIENT LIGHTING LAMP RED/BLU WIRE RED/GRN WIRE RIGHT REAR DOOR COUPLING POINT VIO/BLU WIRE VIO/GRN WIRE YEL/BLK WIRE

Go to component: -> Courtesy lamps circuit (5 of 6) -> PASSENGER SIDE REAR EXIT WARNING LAMP
