Audi SQ8 I (2019-2023) org/wht Wiring diagrams

3.0L TURBO HYBRID 4.0L TURBO HYBRID ACCUMULATOR SOLENOID AUTOMATIC TRANSMISSION CONTROL MODULE FUSE AUTOMATIC TRANSMISSION COUPLING POINT AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 1 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 5 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6 AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 7 BLU/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM ENGINE/MOTOR CONTROL MODULE FUSE 4 FUSE 6 FUSE PANEL D FUSE PANEL E FUSE PANEL G GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES ORG/BRN WIRE ORG/WHT WIRE PARKING LOCK SENSOR PARKING LOCK SOLENOID PNK WIRE RED WIRE RED/GRN WIRE RELAY & FUSE PANEL 2 SOLENOID VALVE 1 SUPPLEMENTAL RESTRAINTS SYSTEM TEMPERATURE SENSOR (IN CONTROL MODULE) TOP OF TRANSMISSION) TRANSMISSION CONTROL MODULE TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1 TRANSMISSION FLUID COOLING VALVE TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION INPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR

AUXILIARY HEATER CONTROL MODULE AUXILIARY HEATER HEATING ELEMENT BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM DEFROSTER DOOR MOTOR FRESH AIR DOOR MOTOR FUSE 1 FUSE 10 FUSE 8 FUSE PANEL B FUSE PANEL C FUSE PANEL D GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT PANEL TEMPERATURE SENSOR INTERIOR REAR VIEW MIRROR LEFT CENTER VENT MOTOR LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR LEFT TEMPERATURE CONTROL DOOR MOTOR LIGHT RECOGNITION SENSOR ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE REAR AIR DISTRIBUTION DOOR MOTOR REAR TEMPERATURE CONTROL DOOR MOTOR RECIRCULATION DOOR MOTOR RED WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RIGHT CENTER VENT MOTOR RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR RIGHT TEMPERATURE CONTROL DOOR MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE WIRE JUNCTION 2 WIRE JUNCTION 2 FUSE 1 YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

A/C CLUTCH BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM DEFROSTER DOOR MOTOR ENGINE COOLANT LEVEL SENSOR FUSE 10 FUSE PANEL C GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER SYSTEM INSTRUMENT PANEL TEMPERATURE SENSOR LEFT CENTER VENT MOTOR LEFT FOOTWELL TEMPERATURE CONTROL DOOR MOTOR LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR LEFT SIDE VENT ADJUSTMENT MOTOR LEFT TEMPERATURE CONTROL DOOR MOTOR ORG/BLU WIRE ORG/BRN WIRE ORG/WHT WIRE ORG/YEL WIRE OUTSIDE AIR TEMPERATURE SENSOR REAR TEMPERATURE CONTROL DOOR MOTOR RED WIRE RED/GRY WIRE RED/YEL WIRE REGULATOR VALVE RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/VIO WIRE

AUXILIARY HEATER CONTROL MODULE AUXILIARY HEATER HEATING ELEMENT BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL COMPUTER DATA LINES SYSTEM DEFROSTER DOOR MOTOR FRESH AIR DOOR MOTOR FUSE 1 FUSE 10 FUSE 12 FUSE PANEL C FUSE PANEL D FUSE PANEL E GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR INSTRUMENT PANEL TEMPERATURE SENSOR INTERIOR REAR VIEW MIRROR LEFT CENTER VENT MOTOR LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR LEFT TEMPERATURE CONTROL DOOR MOTOR LIGHT RECOGNITION SENSOR ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR REAR AIR DISTRIBUTION DOOR MOTOR REAR TEMPERATURE CONTROL DOOR MOTOR RECIRCULATION DOOR MOTOR RED WIRE RED/GRY WIRE RED/YEL WIRE RIGHT CENTER VENT MOTOR RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR RIGHT TEMPERATURE CONTROL DOOR MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE WIRE JUNCTION 2 WIRE JUNCTION 2 FUSE 1 YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

3.0L TURBO HYBRID 4.0L TURBO HYBRID AFTER-RUN COOLANT PUMP BLK WIRE BLK/GRN WIRE BLU/BRN WIRE BLU/RED WIRE BLU/VIO WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DISPLAY UNIT ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE ENGINE PRE-WIRING COUPLING POINT 2 ENGINE/MOTOR CONTROL MODULE FUSE 13 FUSE 14 FUSE 3 FUSE 7 FUSE 8 FUSE PANEL A FUSE PANEL G GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER CONTROL MODULE N/A ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RADIATOR FAN SECOND SPEED FUSE REAR A/C DISPLAY CONTROL HEAD RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR FOOTWELL SEATS SYSTEM TOP OF ENGINE) VIO/YEL WIRE W/ FPK ACTIVE INFO DISPLAY W/O FPK ACTIVE INFO DISPLAY WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/VIO WIRE

3.0L TURBO HYBRID 4.0L TURBO HYBRID A/C CLUTCH A/C COMPRESSOR (LEFT FRONT OF ENGINE) AFTER-RUN COOLANT PUMP BLK WIRE BLK/GRN WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM ENGINE COOLANT LEVEL SENSOR ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE PRE-WIRING COUPLING POINT 2 ENGINE/MOTOR CONTROL MODULE FUSE 13 FUSE 14 FUSE 3 FUSE 8 FUSE PANEL A GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/VIO WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED N/A ORG/BRN WIRE ORG/WHT WIRE OUTSIDE AIR TEMPERATURE SENSOR RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RADIATOR FAN SECOND SPEED FUSE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE REGULATOR VALVE TOP OF ENGINE) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/YEL WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/VIO WIRE

ABS CONTROL MODULE BLK WIRE BLK/BLU WIRE BLK/RED WIRE BRAKE LAMP SWITCH BRAKE PEDAL POSITION SENSOR BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR ENGINE/MOTOR CONTROL MODULE FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FUSE 5 FUSE PANEL A GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GROUND DISTRIBUTION SYSTEM HEADLIGHTS HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP (W/ MATRIX BEAM) LEFT FRONT TURN SIGNAL BULB LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT LED HEADLAMP POWER OUTPUT MODULE 1 ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP (W/ MATRIX BEAM) RIGHT FRONT TURN SIGNAL BULB RIGHT HEADLAMP TEMPERATURE SENSOR 1 RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 SYSTEM TOWING RECOGNITION CONTROL MODULE TURN SIGNAL BULB VIO/RED WIRE WHT/BLK WIRE WHT/GRY WIRE YEL WIRE YEL/BLK WIRE

ACCESS/START AUTHORIZATION BUTTON BATTERY BATTERY INTERRUPT IGNITER BATTERY MONITORING CONTROL MODULE BLK WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CENTER COUPLING POINT ON INSTRUMENT PANEL CHARGING CIRCUIT COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM D/S ENGINE ELECTRONICS FUSE ENGINE/MOTOR CONTROL MODULE FUSE 11 FUSE 5 FUSE 9 FUSE PANEL B FUSE PANEL D FUSE PANEL G GRN WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED NCA WIRE ORG/BRN WIRE ORG/GRY WIRE ORG/WHT WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 1 RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT RIGHT REAR FOOTWELL SELECTOR LEVER SELECTOR LEVER TRANSMISSION RANGE DISPLAY STARTER STARTER RELAY 1 STARTER RELAY 2 SUPPLEMENTAL RESTRAINTS SYSTEM TERMINAL 30 WIRE JUNCTION TRANSMISSION CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/WHT WIRE WHT/GRY WIRE WHT/YEL WIRE YEL/GRY WIRE

ACCELERATOR PEDAL MODULE (ON ACCELERATOR PEDAL ASSEMBLY) ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 BATTERY INTERRUPT IGNITER BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPONENT POWER SUPPLY RELAY ENGINE/MOTOR CONTROL MODULE FUSE 1 FUSE 2 FUSE 3 FUSE PANEL B FUSE PANEL E GRN WIRE GRN/VIO WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ORG/BRN WIRE ORG/WHT WIRE PNK WIRE RED WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 VIO WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
