Audi SQ8 I (2019-2023) folding motor Wiring diagram
This page shows the only wiring diagram for the component.folding motor, which is found in the car Audi SQ8 I (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram folding motor (1 of 1)
ADJUSTMENT MOTOR
ADJUSTMENT MOTOR 2
AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
DRIVER SEAT MEMORY BUTTON
DRIVER SEAT MEMORY SETTINGS CONTROL HEAD
DRIVER SIDE MEMORY SEAT INDICATOR LAMP
EXTERIOR REAR VIEW MIRROR ADJUSTER
FOLDING MOTOR
FUSE 5
FUSE PANEL C
GRN WIRE
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HEATER
HORIZONTAL POSITION SENSOR
HOT AT ALL TIMES
LANE CHANGE ASSISTANCE WARNING LAMP
LEFT FRONT DOOR COUPLING POINT
LEFT PERIPHERAL CAMERA
MEMORY SEAT POSITIONS 1, 2 BUTTON
MIRROR ADJUSTER SWITCH
MIRROR SELECTOR SWITCH
NAVIGATION SYSTEM
NCA WIRE
ORG/BRN WIRE
PNK WIRE
RED WIRE
RED/VIO WIRE
TURN SIGNAL BULB
VERTICAL POSITION SENSOR
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Memory mirrors circuit (1 of 2) -> FOLDING MOTOR
