Audi SQ8 I (2019-2023) driver seat memory settings control head Wiring diagrams

BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER DOOR CONTROL MODULE DRIVER MULTI-CONTOUR SEAT COMPRESSOR DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SEAT VALVE BLOCK 1 DRIVER SEAT VALVE BLOCK 2 DRIVER SIDE MEMORY SEAT INDICATOR LAMP FUSE 5 FUSE PANEL C GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/VIO WIRE W/ MASSAGE YEL WIRE

BLK WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER DOOR CONTROL MODULE DRIVER SEAT LUMBAR SUPPORT DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE MEMORY SEAT INDICATOR LAMP FUSE 5 FUSE PANEL C GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT LUMBAR SUPPORT FORWARD/BACK ADJUSTMENT SENSOR LUMBAR SUPPORT HEIGHT ADJUSTMENT SENSOR MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON ORG/BRN WIRE RED/VIO WIRE VIO WIRE WHT WIRE YEL WIRE

BLU/BRN WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER BACKREST ADJUSTMENT MOTOR DRIVER BACKREST ADJUSTMENT SWITCH DRIVER DOOR CONTROL MODULE DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1 DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ANGLE ADJUSTMENT MOTOR DRIVER SEAT ANGLE ADJUSTMENT SWITCH DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR DRIVER SEAT FORWARD/BACK ADJUSTMENT SWITCH DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT SWITCH DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE MEMORY SEAT INDICATOR LAMP FUSE 5 FUSE PANEL C GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT MEMORY SEAT POSITION 1 BUTTON MEMORY SEAT POSITION 2 BUTTON MEMORY SEAT/ STEERING COLUMN ADJUSTMENT CONTROL MODULE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/VIO WIRE RELAY & FUSE CARRIER 2 WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE

BLK/WHT WIRE BLU/BRN WIRE BLU/YEL WIRE BRN WIRE CENTRAL LOCKING SAFE INDICATOR LAMP COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER DOOR POWER WINDOW CONTROL HEAD DRIVER EXIT WARNING LAMP DRIVER INTERIOR LOCKING BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE DOOR AMBIENT LIGHTING LAMP DRIVER SIDE DOOR SPEAKER TRIM LAMP DRIVER SIDE ENTRY LAMP DRIVER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP EXTERIOR REAR VIEW MIRROR ADJUSTER FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR POWER WINDOW SWITCH FRONT PASSENGER EXIT WARNING LAMP FRONT PASSENGER INTERIOR LOCKING BUTTON FRONT PASSENGER SEAT MEMORY SETTINGS CONTROL HEAD FUSE 14 FUSE 5 FUSE PANEL C FUSE PANEL E GRN WIRE GRN/RED WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT LOADING SILL LOWERING, TRAILER HITCH CONTROL HEAD ORG/BRN WIRE PASSENGER SIDE DOOR SPEAKER TRIM LAMP PASSENGER SIDE ENTRY LAMP PASSENGER SIDE INTERIOR DOOR HANDLE ILLUMINATION LAMP REAR LID REMOTE RELEASE BUTTON RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR AMBIENT LIGHTING BULB 1 RIGHT FRONT DOOR COUPLING POINT TOWING RECOGNITION CONTROL MODULE

ADJUSTMENT MOTOR ADJUSTMENT MOTOR 2 AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER EXTERIOR REAR VIEW MIRROR DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE MEMORY SEAT INDICATOR LAMP EXTERIOR REAR VIEW MIRROR ADJUSTER FOLDING MOTOR FUSE 5 FUSE PANEL C GRN WIRE GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HEATER HORIZONTAL POSITION SENSOR HOT AT ALL TIMES LANE CHANGE ASSISTANCE WARNING LAMP LEFT FRONT DOOR COUPLING POINT LEFT PERIPHERAL CAMERA MEMORY SEAT POSITIONS 1, 2 BUTTON MIRROR ADJUSTER SWITCH MIRROR SELECTOR SWITCH NAVIGATION SYSTEM NCA WIRE ORG/BRN WIRE PNK WIRE RED WIRE RED/VIO WIRE TURN SIGNAL BULB VERTICAL POSITION SENSOR WHT WIRE WHT/YEL WIRE YEL WIRE

BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE DRIVER SEAT MEMORY BUTTON DRIVER SEAT MEMORY SETTINGS CONTROL HEAD DRIVER SIDE MEMORY SEAT INDICATOR LAMP FUSE 15 FUSE 5 FUSE PANEL C FUSE PANEL F GRN WIRE GRY WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT MEMORY SEAT POSITIONS 1, 2 BUTTON ORG/BRN WIRE POWER ADJUSTABLE STEERING COLUMN CONTROL MODULE RED/BLK WIRE RED/VIO WIRE STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN AXIAL ADJUSTMENT SENSOR STEERING COLUMN FORWARD/BACK ADJUSTMENT MOTOR STEERING COLUMN VERTICAL ADJUSTMENT MOTOR STEERING COLUMN VERTICAL ADJUSTMENT SENSOR
