Tire pressure monitoring circuit for Audi SQ7 4M facelift (2019-2024)
Tire pressure monitoring circuit
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 6
FUSE CARRIER 3
FUSE PANEL F
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LEFT COUPLING POINT ON REAR CROSSMEMBER
LEFT FRONT TIRE PRESSURE MONITORING SENSOR, ANTENNA
LEFT REAR TIRE PRESSURE MONITORING SENSOR, ANTENNA
ORG/BRN WIRE
ORG/GRY WIRE
RED/BLU WIRE
RIGHT FRONT TIRE PRESSURE MONITORING SENSOR, ANTENNA
RIGHT REAR TIRE PRESSURE MONITORING SENSOR, ANTENNA
TIRE PRESSURE MONITORING CONTROL MODULE
W/ ACTIVE INFO DISPLAY
W/O ACTIVE INFO DISPLAY
