Trunk & fuel door release circuit for Audi SQ7 4M facelift (2019-2024)

BLU/BLK WIRE BLU/GRY WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 12 FUSE 5 FUSE 9 FUSE CARRIER 1 FUSE CARRIER 3 FUSE PANEL B FUSE PANEL F GRN WIRE GRN/GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE LEFT FRONT DOOR COUPLING POINT LUGGAGE COMPARTMENT COVER DRIVE UNIT LUGGAGE COMPARTMENT COVER MOTOR 1 LUGGAGE COMPARTMENT COVER MOTOR 2 LUGGAGE COMPARTMENT COVER SENSOR ORG/BRN WIRE ORG/GRY WIRE REAR LID CLOSING AID REAR LID CLOSING AID MOTOR REAR LID CONTROL MODULE REAR LID DRIVE UNIT REAR LID DRIVE UNIT 2 REAR LID MOTOR 1 REAR LID MOTOR 1 SENSOR REAR LID MOTOR 1 SENSOR 2 REAR LID MOTOR 2 REAR LID MOTOR 2 SENSOR REAR LID MOTOR 2 SENSOR 2 REAR LID WARNING BUZZER RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 VIO/GRY WIRE VIO/RED WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/GRY WIRE

BLK WIRE BLU WIRE BLU/BRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE FUEL FILLER DOOR LOCK MOTOR (FUEL DOOR LATCH ASSEMBLY) GRN WIRE GRN/RED WIRE GRY/BLU WIRE GRY/GRN WIRE LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LOCK PAWL CONTACT SWITCH LUGGAGE COMPARTMENT REAR LID LOCK BUTTON REAR LID CONTROL HEAD NCA WIRE ORG/BRN WIRE ORG/GRN WIRE POWER REAR LID OPENING CONTROL MODULE POWER REAR LID OPENING SENSOR POWER REAR LID OPENING SENSOR 2 REAR LID CENTRAL LOCKING SYSTEM MOTOR REAR LID CLOSED SENSOR 1, 2 REAR LID CONTACT SWITCH REAR LID CONTROL HEAD REAR LID HANDLE RELEASE BUTTON REAR LID LOCK UNIT REAR LID LOCKING MECHANISM BUTTON REAR LID REMOTE RELEASE BUTTON RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE VIO WIRE WHT/GRN WIRE
