Heated seats circuit for Audi SQ7 4M facelift (2019-2024)

BLK/WHT WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPLING STATION IN LEFT FRONT SEAT FUSE 1 FUSE CARRIER 3 FUSE PANEL B GRN WIRE GRN/BRN WIRE HOT AT ALL TIMES LEFT FRONT SEAT BACKREST TEMPERATURE SENSOR LEFT FRONT SEAT COUPLING STATION LEFT FRONT SEAT HEATED BACKREST LEFT FRONT SEAT HEATED BACKREST, TEMPERATURE SENSOR LEFT FRONT SEAT HEATING ELEMENT LEFT FRONT SEAT HEATING ELEMENT, TEMPERATURE SENSOR LEFT FRONT SEAT TEMPERATURE SENSOR LEFT SEAT BOLSTER HEATING FOR LEFT FRONT SEAT ORG/BRN WIRE RED WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT/BLK WIRE WHT/BLU WIRE WHT/VIO WIRE WHT/YEL WIRE

BLK/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COUPLING STATION IN RIGHT FRONT SEAT FUSE 8 FUSE CARRIER 1 FUSE PANEL F GRN WIRE GRN/BRN WIRE HOT AT ALL TIMES PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE RED WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RIGHT FRONT SEAT BACKREST TEMPERATURE SENSOR RIGHT FRONT SEAT COUPLING STATION RIGHT FRONT SEAT HEATED BACKREST RIGHT FRONT SEAT HEATED BACKREST, TEMPERATURE SENSOR RIGHT FRONT SEAT HEATING ELEMENT RIGHT FRONT SEAT HEATING ELEMENT, TEMPERATURE SENSOR RIGHT FRONT SEAT TEMPERATURE SENSOR RIGHT SEAT BOLSTER HEATING FOR RIGHT FRONT SEAT WHT WIRE WHT/BLK WIRE WHT/VIO WIRE

BLK WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/VIO WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT IN LEFT REAR SEAT COUPLING POINT IN RIGHT REAR SEAT DRIVER SIDE REAR SEAT TEMPERATURE SENSOR GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRN/YEL WIRE LEFT REAR BACKREST HEATING ELEMENT, BACKREST TEMPERATURE SENSOR LEFT REAR BACKREST SEAT HEATING ELEMENT LEFT REAR BENCH SEAT HEATING ELEMENT LEFT REAR BENCH SEAT HEATING ELEMENT, DRIVER SIDE REAR SEAT TEMPERATURE SENSOR LEFT REAR SEAT BACKREST TEMPERATURE SENSOR LEFT REAR SEAT COUPLING STATION ORG/BRN WIRE PASSENGER SIDE REAR SEAT TEMPERATURE SENSOR REAR A/C DISPLAY CONTROL HEAD RED WIRE RED/VIO WIRE RIGHT REAR BACKREST HEATING ELEMENT, BACKREST TEMPERATURE SENSOR RIGHT REAR BACKREST SEAT HEATING ELEMENT RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR SEAT BACKREST TEMPERATURE SENSOR RIGHT REAR SEAT COUPLING STATION YEL WIRE YEL/BLU WIRE YEL/GRN WIRE
