Automatic a/c circuit, w/o rear controls & second heating system for Audi SQ7 4M facelift (2019-2024)

BLK/BRN WIRE BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DEFROSTER DOOR MOTOR ENGINE COOLANT LEVEL SENSOR FRESH AIR DOOR MOTOR FRONT HEATING, AIR CONDITIONING COUPLING POINT FUSE 10 FUSE 8 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL B GRN WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT PANEL TEMPERATURE SENSOR LEFT CENTER VENT MOTOR LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR LEFT TEMPERATURE CONTROL DOOR MOTOR ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/WHT WIRE OUTSIDE AIR TEMPERATURE SENSOR REAR AIR DISTRIBUTION DOOR MOTOR REAR TEMPERATURE CONTROL DOOR MOTOR RECIRCULATION DOOR MOTOR RED WIRE RED/BLU WIRE RED/GRY WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 RIGHT CENTER VENT MOTOR RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR RIGHT TEMPERATURE CONTROL DOOR MOTOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/VIO WIRE

A/C CLUTCH, A/C COMPRESSOR REGULATOR VALVE AIR QUALITY SENSOR AUTOMATIC TRANSMISSION COUPLING POINT AUXILIARY HEATER CONTROL MODULE AUXILIARY HEATER HEATING ELEMENT BLK/GRN WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLK WIRE COOLANT SHUT-OFF VALVE EVAPORATOR VENT TEMPERATURE SENSOR FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE FUSE 1 GRY WIRE GRY/BRN WIRE GRY/RED WIRE HIGH PRESSURE SENSOR HOT AT ALL TIMES LEFT FOOTWELL VENT TEMPERATURE SENSOR MAIN FUSE CARRIER ON BATTERY RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT FOOTWELL VENT TEMPERATURE SENSOR SAFETY FUSE 4 VIO/WHT WIRE W/ REAR AXLE STEERING W/O REAR AXLE STEERING WIRE JUNCTION YEL/VIO WIRE

2.0L TURBO 3.0L TURBO HYBRID 4.0L TURBO HYBRID BLK WIRE BLK/GRN WIRE BLU/GRN WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE/MOTOR CONTROL MODULE FUSE 13 FUSE 14 FUSE 4 FUSE 8 FUSE PANEL 1 FUSE PANEL B GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/VIO WIRE HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT PNK WIRE POWER DISTRIBUTION SYSTEM RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 2 TRANSMISSION COOLANT VALVE VIO/BLK WIRE VIO/WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE YEL/RED WIRE YEL/VIO WIRE

2.0L TURBO 3.0L TURBO HYBRID 3.0L TURBO HYBRID 4.0L TURBO HYBRID 4.0L TURBO HYBRID AFTER-RUN COOLANT PUMP BLK WIRE BLU/YEL WIRE BRN WIRE COOLANT RECIRCULATION PUMP FUSE 3 FUSE 4 FUSE PANEL 1 FUSE PANEL B GRN/VIO WIRE GRN/WHT (OR VIO/YEL) WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/ MOTOR COMPARTMENT RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE RADIATOR FAN SECOND SPEED FUSE RADIATOR SHUTTER MOTOR RED/BLU WIRE RED/GRN (OR RED/BLU) WIRE RED/GRN WIRE RED/WHT WIRE RELAY & FUSE CARRIER 2 SUPPRESSOR TERMINAL 30 WIRE JUNCTION/ TERMINAL 30 WIRE JUNCTION 2 VIO/BLK WIRE WHT/VIO WIRE YEL/RED WIRE YEL/VIO WIRE
