Car Wiring Diagrams for Radio circuit, w/ bang & olufsen sound for Audi SQ5 II (2017-2020)

ANTENNA AMPLIFIER 2 ANTENNA AMPLIFIER ANTENNA BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM COUPLING POINT ON RIGHT A-PILLAR BRN WIRE COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA FUSE 10 FUSE 5 FUSE PANEL C GPS ANTENNA GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LTE ANTENNA 1 LTE ANTENNA 2 MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/RED WIRE ORG/VIO WIRE RADIO ANTENNA 2 RED WIRE RED/BLK WIRE RED/YEL WIRE ROOF ANTENNA SATELLITE TUNER ANTENNA W/ MOBILE ONLINE SERVICES WHT WIRE

AUX BLK WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER VOLUME CONTROL EXTERNAL AUDIO SOURCE CONNECTION GRN WIRE GRY WIRE GRY/RED WIRE GRY/YEL WIRE INSTRUMENT CLUSTER CONTROL MODULE MULTIMEDIA BUTTON MODULE MULTIMEDIA SYSTEM CONTROL HEAD ORG/ WIRE ORG/BRN WIRE ORG/RED WIRE ORG/VIO WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE USB VEHICLE ELECTRICAL SYSTEM CONTROL MODULE YEL WIRE

BLK WIRE BLU WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE CENTER COUPLING POINT IN INTERIOR COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD FUSE 14 FUSE 8 FUSE PANEL C GRN WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 INTERIOR MICROPHONE LEFT FRONT MICROPHONE MOST DATA BUS CIRCUIT NAVIGATION SYSTEM NCA WIRE ORG/ WIRE ORG/BRN WIRE ORG/RED WIRE ORG/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MICROPHONE STANDARD HIGH VIO/GRY WIRE WHT WIRE

BLK WIRE BLU/YEL WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BOTTOM LEFT FRONT TREBLE SPEAKER BOTTOM RIGHT FRONT TREBLE SPEAKER BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE CENTER SPEAKER CENTER SPEAKER 2 DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT SIDE OF CARGO AREA) FUSE 2 FUSE PANEL 5 FUSE PANEL F GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT EFFECTS SPEAKER LEFT FRONT BASS SPEAKER LEFT FRONT DOOR COUPLING POINT LEFT FRONT MIDRANGE SPEAKER LEFT FRONT MIDRANGE SPEAKER 2 LEFT REAR BASS SPEAKER LEFT REAR DOOR COUPLING POINT LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RELAY & FUSE PANEL 2 RIGHT EFFECTS SPEAKER RIGHT FRONT BASS SPEAKER RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT MIDRANGE SPEAKER RIGHT FRONT MIDRANGE SPEAKER 2 RIGHT REAR BASS SPEAKER RIGHT REAR DOOR COUPLING POINT RIGHT REAR TREBLE SPEAKER SUBWOOFER TOP LEFT FRONT TREBLE SPEAKER 2 TOP RIGHT FRONT TREBLE SPEAKER 2 VIO/BLU WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BRN WIRE YEL/RED WIRE
