Audi SQ5 II (2017-2020) wht Wiring diagrams
This page contains all the electrical diagrams for the component. wht, in which he is found in the car Audi SQ5 II (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wht (51 of 86)
ACTIVE STEERING CONTROL MODULE
ACTIVE STEERING MOTOR
ACTIVE STEERING MOTOR ROTOR POSITION SENSOR
ACTIVE STEERING SAFETY LOCK ACTUATOR
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
FUSE 10
FUSE PANEL 5
FUSE PANEL B
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
NCA WIRE
PNK WIRE
PNK/WHT WIRE
RED WIRE
RELAY & FUSE PANEL 1
SUPPLEMENTAL RESTRAINTS SYSTEM
WHT WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Active steering control module circuit -> WHT WIRE
Wiring diagram wht (52 of 86)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER COUPLING POINT IN INTERIOR
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE (BELOW REAR SEAT CENTER ARM REST)
DISPLAY UNIT
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE ANTENNA
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
FRONT INFORMATION DISPLAY CONTROL HEAD
FRONT ROOF MODULE
GPS ANTENNA
GRN WIRE
GRY WIRE
GRY/BLK WIRE
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/RED WIRE
ORG/VIO WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT EMERGENCY FLASHER INDICATOR LAMP
ROAD SIDE ASSISTANCE BUTTON
ROOF ANTENNA (IF EQUIPPED)
TELEMATICS EMERGENCY BATTERY
VIO/GRY WIRE
VIO/RED WIRE
W/ HEAT INSULATING WINDSHIELD
W/ INSULATING WINDSHIELD
W/ PANORAMA SUNROOF
WHT WIRE
Go to component -> Emergency call circuit (2 of 2) -> WHT WIRE
Wiring diagram wht (53 of 86)
ANTI-THEFT ALARM SYSTEM SENSOR
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
FUSE 1
FUSE 2
FUSE 3
FUSE PANEL 1
FUSE PANEL 4
FUSE PANEL B
FUSE PANEL F
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT WINDSHIELD DEFOGGER RELAY
NCA WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
RELAY & FUSE PANEL 2
RIGHT WINDSHIELD DEFOGGER RELAY
VIO/BRN WIRE
VIO/GRY WIRE
WHT WIRE
WINDSHIELD DEFOGGER
WINDSHIELD DEFOGGER RELAY
YEL WIRE
Go to component -> Heated windshield circuit -> WHT WIRE
Wiring diagram wht (54 of 86)
2.0L TURBO
3.0L TURBO
ABS IND LAMP
AIR BAG IND LAMP
BLK WIRE
BLU WIRE
BRAKE SYSTEM IND LAMP
BRN WIRE
CENTER COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL IND LAMP
DIESEL ELECTRONICS IND LAMP
DISPLAY UNIT
ELECTROMECHANICAL POWER STEERING IND LAMP
ENGINE ELECTRONICS IND LAMP
ENGINE/MOTOR CONTROL MODULE
FUEL GAUGE
FUSE 11
FUSE 4
FUSE 9
FUSE PANEL C
GRN WIRE
GRN/VIO WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LANE CHANGE ASSISTANCE IND LAMP
LEFT TURN SIGNAL IND LAMP
OIL PRESSURE SWITCH
ORG/ WIRE
ORG/BRN WIRE
ORG/VIO WIRE
PARKING BRAKE IND LAMP
PNK WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT EMERGENCY FLASHER IND LAMP
SOUND SYSTEMS
WHT WIRE
WHT/GRY WIRE
WHT/VIO WIRE
WINDSHIELD PROJECTION HEAD UP DISPLAY CONTROL MODULE
Go to component -> Instrument cluster circuit (1 of 2) -> WHT WIRE
Wiring diagram wht (55 of 86)
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
BRN/BLU WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVING PROFILE SELECTION BUTTON
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1
EMERGENCY FLASHER BUTTON
ENGINE COOLANT LEVEL SENSOR
FRONT DISPLAY OPEN/CLOSE BUTTON
FUEL DELIVERY UNIT
FUEL LEVEL SENSOR
FUEL LEVEL SENSOR 2
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
INSTRUMENT CLUSTER OPERATION BUTTON
LIGHT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
OUTSIDE AIR TEMPERATURE SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/YEL WIRE
WINDSHIELD PROJECTION HEAD-UP DISPLAY BUTTON
WINDSHIELD WASHER FLUID LEVEL SENSOR
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> WHT WIRE
Wiring diagram wht (56 of 86)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 4
FUSE PANEL 3
FUSE PANEL F
GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LANE CHANGE ASSISTANCE INDICATOR LAMP
LANE CHANGE ASSISTANCE WARNING LAMP
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
ORG/WHT WIRE
RELAY & FUSE PANEL 2
WHT WIRE
Go to component -> Lane change assistance circuit -> WHT WIRE
Wiring diagram wht (57 of 86)
ANTENNA
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
BLK WIRE
BLK/RED WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
FUSE 5
FUSE PANEL C
GRN WIRE
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT BASS SPEAKER
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT TREBLE SPEAKER
LEFT REAR BASS SPEAKER
LEFT REAR DOOR COUPLING POINT
LEFT REAR TREBLE SPEAKER
NAVIGATION SYSTEM (PERIPHERAL CAMERA CIRCUIT)
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/RED WIRE
ORG/VIO WIRE
RADIO ANTENNA 2
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SOUND SYSTEM (MOST DATA BUS CIRCUIT)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Navigation circuit (1 of 4) -> WHT WIRE
Wiring diagram wht (58 of 86)
AUX
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BOTTOM COUPLING POINT ON RIGHT A-PILLAR
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
EXTERNAL AUDIO SOURCE CONNECTION
GRN WIRE
GRY WIRE
GRY/RED WIRE
GRY/YEL WIRE
INSTRUMENT CLUSTER CONTROL MODULE
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR BASS SPEAKER
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR TREBLE SPEAKER
USB
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit (2 of 4) -> WHT WIRE
Wiring diagram wht (59 of 86)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CENTER COUPLING POINT IN INTERIOR
CENTER SPEAKER
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE 10
FUSE 14
FUSE 8
FUSE PANEL C
GRN WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
MOST DATA BUS CIRCUIT
MULTIMEDIA BUTTON MODULE
MULTIMEDIA SYSTEM CONTROL HEAD
NAVIGATION SYSTEM (REAR VIEW CAMERA CIRCUIT)
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/RED WIRE
ORG/VIO WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
SOUND SYSTEM
STANDARD HIGH
VIO/GRY WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Navigation circuit (4 of 4) -> WHT WIRE
Wiring diagram wht (60 of 86)
BLK WIRE
BLK/BLU WIRE
BRN WIRE
BRN/WHT WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
FRONT A/C DISPLAY CONTROL HEAD
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 11
FUSE 14
FUSE 5
FUSE 7
FUSE PANEL 1
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL B
FUSE PANEL F
GRN/VIO WIRE
HEATED MIRROR
HOT AT ALL TIMES
INTERMEDIATE CIRCUIT CAPACITOR 1
LEFT FRONT DOOR COUPLING POINT
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SUPPRESSOR
REAR WINDOW DEFOGGER SUPPRESSOR 2
RED/VIO WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 1
RELAY & FUSE PANEL 2
RIGHT FRONT DOOR COUPLING POINT
WHT WIRE
WHT/YEL WIRE
WINDSHIELD ANTENNA SUPPRESSION FILTER
Go to component -> Rear defogger & heated mirrors circuit -> WHT WIRE
