Audi SQ5 II (2017-2020) right radiator fan Wiring diagrams
This page contains all the electrical diagrams for the component. right radiator fan, in which he is found in the car Audi SQ5 II (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right radiator fan (1 of 3)
2.0L TURBO
3.0L TURBO
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CENTER COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
COMPUTER DATA LINES SYSTEM
COOLANT RECIRCULATION PUMP
COOLANT SHUT-OFF VALVE
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 2
FUSE 3
FUSE 4
FUSE PANEL 1
FUSE PANEL A
FUSE PANEL B
GRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
N/A
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RELAY & FUSE PANEL 1
RIGHT RADIATOR FAN
SUPPRESSOR
VIO/WHT WIRE
VIO/YEL WIRE
W/ TRAILER HITCH W/O TRAILER HITCH 2.0L TURBO 3.0L TURBO
W/O TRAILER HITCH
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/ climatronic (3 of 3) -> RIGHT RADIATOR FAN
Wiring diagram right radiator fan (2 of 3)
2.0L TURBO
3.0L TURBO
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CENTER COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
COMPUTER DATA LINES SYSTEM
COOLANT RECIRCULATION PUMP
COOLANT SHUT-OFF VALVE
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 2
FUSE 3
FUSE 4
FUSE PANEL 1
FUSE PANEL A
FUSE PANEL B
GRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
N/A
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RELAY & FUSE PANEL 1
RIGHT RADIATOR FAN
SUPPRESSOR
VIO/WHT WIRE
VIO/YEL WIRE
W/ TRAILER HITCH W/O TRAILER HITCH 2.0L TURBO 3.0L TURBO
W/O TRAILER HITCH
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/o climatronic (4 of 4) -> RIGHT RADIATOR FAN
Wiring diagram right radiator fan (3 of 3)
2.0L TURBO
3.0L TURBO
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
CENTER COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
COMPUTER DATA LINES SYSTEM
COOLANT RECIRCULATION PUMP
COOLANT SHUT-OFF VALVE
ENGINE COOLANT LEVEL SENSOR
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE
ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 2
FUSE 3
FUSE 4
FUSE PANEL 1
FUSE PANEL A
FUSE PANEL B
GRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
N/A
ORG/BRN WIRE
ORG/GRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR
RADIATOR FAN
RADIATOR FAN 2
RADIATOR FAN CONTROL MODULE
RADIATOR FAN CONTROL MODULE 2
RADIATOR FAN FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RELAY & FUSE PANEL 1
RIGHT RADIATOR FAN
SUPPRESSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
VIO/YEL WIRE
W/ TRAILER HITCH W/O TRAILER HITCH 2.0L TURBO 3.0L TURBO
W/O TRAILER HITCH
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Cooling fan circuit -> RIGHT RADIATOR FAN
