Audi SQ5 II (2017-2020) fuse panel 4 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse panel 4, in which he is found in the car Audi SQ5 II (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fuse panel 4 wiring diagram (1 of 21)
AUTOMATIC DIMMING EXTERIOR REAR VIEW MIRROR
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON ROOF
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 1
FUSE 12
FUSE 14
FUSE 5
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL 4
FUSE PANEL B
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
HUMIDITY SENSOR
LEFT FRONT DOOR COUPLING POINT
LIGHT RECOGNITION SENSOR
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
RED WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 1
RIGHT FRONT DOOR COUPLING POINT
SUNLIGHT PHOTO SENSOR
VIO/RED WIRE
VIO/WHT WIRE
W/ HIGH BEAM ASSIST W/O HIGH BEAM ASSIST
Go to component -> Automatic day/night mirror circuit -> FUSE PANEL 4
fuse panel 4 wiring diagram (2 of 21)
2.0L TURBO
3.0L TURBO, 2.0L TURBO
ACTIVE STEERING CONTROL MODULE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
DATA BUS ON BOARD DIAGNOSTIC INTERFACE (BELOW REAR SEAT CENTER ARM REST)
DIAGNOSTIC CONNECTION
DUAL-CLUTCH TRANSMISSION MECHATRONIC
FUSE 1
FUSE 12
FUSE 2
FUSE 7
FUSE PANEL 2
FUSE PANEL 4
FUSE PANEL B
GRN WIRE
GRN/WHT WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/RED WIRE
ORG/VIO WIRE
PNK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION SYSTEM
POWER STEERING CONTROL MODULE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
RIGHT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
SELECTOR LEVER
TRANSMISSION CONTROL MODULE (3.0L TURBO) (LOWER FRONT OF TRANSMISSION)
VIO/WHT WIRE
VIO/YEL WIRE
Go to component -> Computer data lines circuit (1 of 8) -> FUSE PANEL 4
fuse panel 4 wiring diagram (3 of 21)
BLK/BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DISPLAY UNIT
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT
EMERGENCY FLASHER BUTTON
FUSE 12
FUSE 13
FUSE PANEL 4
FUSE PANEL B
HEADLIGHTS SYSTEM
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
IND LAMP
INSTRUMENT CLUSTER CONTROL MODULE
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP BULB
LEFT FRONT STRUT TOWER)
LEFT FRONT TURN SIGNAL BULB
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LIGHT CONTROL MODULE
LEFT STATIONARY CORNERING LAMP
LEFT TURN SIGNAL INDICATOR LAMP
ORG/BRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
RED WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
RIGHT EMERGENCY FLASHER INDICATOR LAMP
VIO/WHT WIRE
W/ HID
W/O HID W/ MATRIX BEAM W/O HID, MATRIX BEAM
W/O HID, MATRIX BEAM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Exterior lamps circuit (2 of 7) -> FUSE PANEL 4
fuse panel 4 wiring diagram (4 of 21)
BLK/BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 11
FUSE 12
FUSE 13
FUSE 3
FUSE 9
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL 4
FUSE PANEL B
FUSE PANEL C
GRY/RED WIRE
HEADLAMP SWITCH ILLUMINATION BULB
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
HUMIDITY SENSOR
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT SIDE MARKER LAMP BULB
LEFT FRONT STRUT TOWER)
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HEADLAMP CURRENT CODING RESISTANCE 1
LEFT HEADLAMP CURRENT CODING RESISTANCE 2
LEFT HEADLAMP CURRENT CODING RESISTANCE 3
LEFT HEADLAMP CURRENT CODING RESISTANCE 4
LEFT HEADLAMP CURRENT CODING RESISTANCE 5
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HEADLAMP TEMPERATURE SENSOR 2
LEFT HEADLAMP TEMPERATURE SENSOR 3
LEFT HEADLAMP TEMPERATURE SENSOR 4
LEFT HEADLAMP TEMPERATURE SENSOR 5
LEFT HIGH BEAM HEADLAMP BULB
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LIGHT CONTROL MODULE
LEFT LOW BEAM HEADLAMP BULB
LEFT STATIONARY CORNERING LAMP
LIGHT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
POSITION LAMP INDICATOR LAMP
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD PROJECTION HEAD-UP DISPLAY BUTTON
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, w/o hid & matrix beam (1 of 2) -> FUSE PANEL 4
fuse panel 4 wiring diagram (5 of 21)
BLK/BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FOG LAMP BUTTON
FOG LAMP INDICATOR LAMP
FUSE 11
FUSE 12
FUSE 13
FUSE 3
FUSE 9
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL 4
FUSE PANEL B
FUSE PANEL C
GRY/RED WIRE
HEADLAMP SWITCH ILLUMINATION BULB
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
HUMIDITY SENSOR
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT PANEL, SWITCH ILLUMINATION DIMMER SWITCH
LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE
LEFT FRONT HEADLAMP
LEFT FRONT STRUT TOWER)
LEFT FRONT TURN SIGNAL BULB
LEFT HEADLAMP AUXILIARY FUNCTIONS POWER OUTPUT MODULE
LEFT HEADLAMP BEAM ADJUSTMENT MOTOR
LEFT HEADLAMP CURRENT CODING RESISTANCE 1
LEFT HEADLAMP CURRENT CODING RESISTANCE 2
LEFT HEADLAMP CURRENT CODING RESISTANCE 3
LEFT HEADLAMP CURRENT CODING RESISTANCE 4
LEFT HEADLAMP FAN
LEFT HEADLAMP TEMPERATURE SENSOR 1
LEFT HEADLAMP TEMPERATURE SENSOR 2
LEFT HEADLAMP TEMPERATURE SENSOR 3
LEFT HEADLAMP TEMPERATURE SENSOR 4
LEFT HEADLAMP TEMPERATURE SENSOR 5
LEFT HIGH BEAM HEADLAMP BULB
LEFT LED HEADLAMP POWER OUTPUT MODULE 1
LEFT LIGHT CONTROL MODULE
LEFT LOW BEAM HEADLAMP BULB
LEFT MATRIX HEADLAMP POWER OUTPUT MODULE
LEFT STATIONARY CORNERING LAMP
LIGHT SWITCH
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/VIO WIRE
POSITION LAMP INDICATOR LAMP
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
REAR FOG LAMP BUTTON
REAR FOG LAMP INDICATOR LAMP
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD PROJECTION HEAD-UP DISPLAY BUTTON
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Headlights circuit, w/o hid w/ matrix beam (1 of 2) -> FUSE PANEL 4
fuse panel 4 wiring diagram (6 of 21)
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DRIVER SEAT BACKREST COUPLING POINT
FUSE 1
FUSE PANEL 3
FUSE PANEL 4
FUSE PANEL B
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT CUSHION FAN 1
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
VIO/WHT WIRE
WHT/YEL WIRE
Go to component -> Heated seats circuit, w/ ventilation (1 of 2) -> FUSE PANEL 4
fuse panel 4 wiring diagram (7 of 21)
Go to component -> Lane departure warning circuit -> FUSE PANEL 4
fuse panel 4 wiring diagram (8 of 21)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 16
FUSE PANEL 4
FUSE PANEL B
GRY WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT FRONT SEAT COUPLING STATION
LEFT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE
MULTIMEDIA DISPLAY UNIT 3
MULTIMEDIA DISPLAY UNIT 3 BRACKET
MULTIMEDIA DISPLAY UNIT 4
MULTIMEDIA DISPLAY UNIT 4 BRACKET
N/A
NCA WIRE
PNK WIRE
RED WIRE
RED/BLU WIRE
RELAY & FUSE PANEL 1
RIGHT FRONT SEAT COUPLING STATION
RIGHT REAR INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Rear seat entertainment circuit -> FUSE PANEL 4
fuse panel 4 wiring diagram (9 of 21)
BLK WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1
FUSE 11
FUSE 5
FUSE PANEL 1
FUSE PANEL 4
FUSE PANEL 5
FUSE PANEL B
FUSE PANEL F
GRY/RED WIRE
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
RELAY & FUSE PANEL 1 (LEFT KICK PANEL)
RELAY & FUSE PANEL 2
START/ STOP MODE BUTTON
START/ STOP MODE INDICATOR LAMP
TERMINAL 15 POWER SUPPLY RELAY
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
WHT WIRE
Go to component -> Starting circuit (2 of 2) -> FUSE PANEL 4
fuse panel 4 wiring diagram (10 of 21)
AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BRN WIRE
BRN/BLU WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMPUTER DATA LINES SYSTEM
COUPLING POINT ON ROOF
DISPLAY UNIT
FUSE 1
FUSE 10
FUSE 12
FUSE 14
FUSE 2
FUSE PANEL 2
FUSE PANEL 3
FUSE PANEL 4
FUSE PANEL B
FUSE PANEL C
FUSE PANEL F
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/WHT WIRE
HEADLAMP WASHER SYSTEM PUMP
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
HUMIDITY SENSOR (IF EQUIPPED)
IF EQUIPPED W/ HIGH BEAM ASSIST W/O HIGH BEAM ASSIST
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT CLUSTER SYSTEM
LIGHT RECOGNITION SENSOR
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RAIN/LIGHT RECOGNITION SENSOR
REAR WINDOW WIPER MOTOR
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RELAY & FUSE PANEL 1
RELAY & FUSE PANEL 2
STEERING COLUMN ELECTRONICS CONTROL MODULE
SUNLIGHT PHOTO SENSOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/VIO WIRE
WINDSHIELD WASHER FLUID LEVEL SENSOR
WINDSHIELD WASHER PUMP
WINDSHIELD WIPER INTERMITTENT MODE SWITCH
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER SWITCH
WIPER MOTOR CONTROL MODULE
YEL WIRE
YEL/RED WIRE
Go to component -> Wiper/washer circuit -> FUSE PANEL 4
