Audi SQ5 II (2017-2020) emergency call module microphone Wiring diagram
This page shows the only wiring diagram for the component.emergency call module microphone, which is found in the car Audi SQ5 II (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram emergency call module microphone (1 of 1)
BLK WIRE
BLU WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER VOLUME CONTROL
EMERGENCY CALL MODULE MICROPHONE
FUSE 10
FUSE 14
FUSE 8
FUSE PANEL 2
FUSE PANEL B
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MICROPHONE
MICROPHONE UNIT
MULTIMEDIA BUTTON MODULE
MULTIMEDIA SYSTEM CONTROL HEAD
ORG/ WIRE
ORG/BRN WIRE
ORG/RED WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 1
RIGHT FRONT MICROPHONE
STANDARD HIGH
VIO/GRY WIRE
WHT WIRE
Go to component -> Emergency call circuit (1 of 2) -> EMERGENCY CALL MODULE MICROPHONE
