Audi SQ5 II (2017-2020) cup holder w/ heating, cooling element Wiring diagrams
This page contains all the electrical diagrams for the component. cup holder w/ heating, cooling element, in which he is found in the car Audi SQ5 II (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cup holder w/ heating, cooling element (1 of 2)
BRN WIRE
COMPUTER DATA LINES SYSTEM
CUP HOLDER W/ HEATING, COOLING ELEMENT
CUPHOLDER AMBIENT LIGHTING LAMP
CUPHOLDER COOLING ELEMENT BUTTON
CUPHOLDER COOLING INDICATOR LAMP
CUPHOLDER HEATING ELEMENT BUTTON
CUPHOLDER HEATING INDICATOR LAMP
FUSE 9
FUSE PANEL 3
FUSE PANEL F
HOT AT ALL TIMES
LEFT CUPHOLDER ILLUMINATION BULB
RED/BLU WIRE
RELAY & FUSE PANEL 2
RIGHT CUPHOLDER ILLUMINATION BULB
VIO/RED WIRE
Go to component -> Heated and cooled cup holder circuit -> CUP HOLDER W/ HEATING, COOLING ELEMENT
Wiring diagram cup holder w/ heating, cooling element (2 of 2)
7 SPEED A/T
AUTOMATIC TRANSMISSION CONTROL MODULE FUSE
BLK/RED WIRE
BLK/WHT WIRE
CELLULAR TELEPHONE AMPLIFIER
COMFORT SYSTEM CENTRAL CONTROL MODULE
CUP HOLDER W/ HEATING, COOLING ELEMENT
DIFFERENTIAL LOCK CONTROL MODULE
DIGITAL SOUND SYSTEM CONTROL MODULE
DUAL-CLUTCH TRANSMISSION MECHATRONIC
FROM MAIN FUSE CARRIER (DIAGRAM 1 OF 6)
FUEL TANK COUPLING POINT
FUEL TANK LEAK DETECTION MODULE
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 8
FUSE 9
FUSE PANEL 3
FUSE PANEL 5
FUSE PANEL F
GARAGE DOOR OPENER CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
LEFT FRONT SEAT COUPLING STATION
N/A
PERIPHERAL CAMERA CONTROL MODULE
REAR VIEW CAMERA SYSTEM CONTROL MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT LUMBAR SUPPORT ADJUSTMENT SWITCH
RIGHT FRONT SEAT BELT
RIGHT FRONT SEAT COUPLING STATION
TELEPHONE BASEPLATE
TOWING RECOGNITION CONTROL MODULE
TV TUNER
W/ CELLPHONE AMPLIFIER
W/ MANUALLY SWIVELING
W/ REAR VIEW CAMERA W/O REAR VIEW CAMERA
W/O ADJUSTABLE SEATS
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit (5 of 6) -> CUP HOLDER W/ HEATING, COOLING ELEMENT
