Audi SQ5 II (2017-2020) coupling point in the right rear door Wiring diagram
This page shows the only wiring diagram for the component.coupling point in the right rear door, which is found in the car Audi SQ5 II (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coupling point in the right rear door (1 of 1)
BRN WIRE
BRN/YEL WIRE
COUPLING POINT IN THE RIGHT REAR DOOR
DOOR CONTACT SWITCH
DRIVER SIDE REAR DOOR AMBIENT LIGHT LAMP
DRIVER SIDE REAR DOOR CONTROL MODULE
DRIVER SIDE REAR DOOR LOCK UNIT
DRIVER SIDE REAR ENTRY LAMP
DRIVER SIDE REAR EXIT WARNING LAMP
DRIVER SIDE REAR POWER WINDOW BUTTON
GRN WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT ILLUMINATION CIRCUIT
PASSENGER SIDE REAR DOOR CONTROL MODULE
PASSENGER SIDE REAR DOOR LOCK UNIT
PASSENGER SIDE REAR EXIT WARNING LAMP
RED/BLU WIRE
RIGHT REAR DOOR
RIGHT REAR DOOR AMBIENT LIGHTING BULB 1
RIGHT REAR DOOR CONTOUR ILLUMINATION LAMP
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR DOOR STORAGE COMPARTMENT ILLUMINATION LAMP
VIO WIRE
VIO/BRN WIRE
VIO/YEL WIRE
W/ AUXILIARY LAMPS
W/ CHILD SAFETY LOCK
W/O CHILD SAFETY LOCK
W/O CHILD SAFETY LOCK W/ CHILD SAFETY LOCK
Go to component -> Courtesy lamps circuit (5 of 6) -> COUPLING POINT IN THE RIGHT REAR DOOR
