Jet heater circuit for Audi SQ5 Sportback FY (2020-2024)

Jet heater circuit

Get access

BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 10 FUSE PANEL 3 FUSE PANEL B GRY WIRE HOT AT ALL TIMES LEFT WASHER NOZZLE HEATER ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/GRY WIRE RELAY & FUSE PANEL 1 RIGHT WASHER NOZZLE HEATER VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE YEL WIRE YEL/WHT WIRE
